Samson 2417 Series User Manual

EB 2517 EN 37
Servicing
Table7: Set point adjustment · Dimension x
Set point range Valve size DN
8 to 16bar 15 to 25 32 to 50 65 to 100
10bar x=89mm x=111mm x=153mm
12bar x=97mm x=122mm x=170mm
14bar x=104mm x=133mm x=188mm
4.5 to 10bar
Set point
5.9bar x=85mm x=105mm x=151mm
7.3bar x=93mm x=117mm x=172mm
8.6bar x=101mm x=123mm x=192mm
2 to 5bar
Set point
2.8bar x=83mm x=102mm x=146mm
3.5bar x=92mm x=115mm x=168mm
4.3bar x=100mm x=127mm x=190mm
0.8 to 2.5bar
Set point
1.2bar x=79mm x=97mm x=137mm
1.7bar x=89mm x=111mm x=162mm
2.1bar x=99mm x=126mm x=187mm
0.2 to 1.2bar
Set point
0.45bar x=71mm x=86mm x=118mm
0.70bar x=83mm x=103mm x=147mm
1.0bar x=95mm x=120mm x=177mm
0.1 to 0.6bar
Set point
0.23bar x=71mm x=86mm x=118mm
0.35bar x=83mm x=103mm x=147mm
0.48bar x=95mm x=120mm x=177mm
0.05 to 0.25bar
Set point
0.10bar x=70mm x=85mm x=112mm
0.15bar x=81mm x=100mm x=136mm
0.20bar x=91mm x=115mm x=159mm
Set point
7 Servicing
The regulator does not require any mainte-
nance. Nevertheless, it is subject to natural
wear, particularly at the seat, plug and oper-
ating diaphragm/bellows. Depending on the
operating conditions, check the regulator at
regular intervals to avoid possible malfunc-
tions.
We recommend removing the regulator from
the pipeline before performing any mainte-
nance or service work.
Risk of bursting in pressure equipment.
Regulators and pipelines are pressure equip-
ment. Improper opening can lead to bursting
of the regulator.
− Before starting any work on the regulator,
depressurize all plant sections concerned
as well as the regulator.
− Disconnect the control line.
− Drain the process medium from all the
plant sections concerned as well as the
regulator.
− Wear personal protective equipment.
Risk of personal injury due to residual pro-
cess medium in the regulator.
While working on the regulator, residual
process medium can escape and, depending
on its properties, may lead to personal in-
jury, e.g. (chemical) burns.
Wear protective clothing, safety gloves and
eyewear.
DANGER
!
WARNING
!
