Appendix
10 Appendix
10.1 After-sales service
Contact SAMSON's After-sales Service de-
partment for support concerning service or
repair work or when malfunctions or defects
arise.
E-mail address
You can reach the After-sales Service De-
partment at aftersalesservice@samson.de.
Addresses of SAMSONAG and its subsid-
iaries
The addresses of SAMSON, its subsidiaries,
representatives and service facilities world-
wide can be found on our website
(uwww.samson.de)orinallSAMSON
product catalogs.
To assist diagnosis and in case of an unclear
mounting situation, specify the following de-
tails(sofaraspossible).Seesection2:
– Devicetypeandnominalsize
– ModelnumberandcongurationID
– Upstream and downstream pressure
– Temperature and process medium
– Min.andmax.owrate
– Is a strainer installed?
– Installationdrawingshowingtheexact
location of the regulator and all the ad-
ditionally installed components (shut-off
valves, pressure gauge etc.)
10.2 Spare parts
Version (2012 onwards)
2 Bellows assembly
6 Coupling nut
12 Balancing screw
16 Seat
17 Plug
20 Body
21 Guidecap
25 Guide(DN32to100)
25, 26 Guidebushing/pipe(DN15to25)
27 Flanged pipe
28 Washer
34 Flange
40 Set point adjuster
44 Stud bolt
46 Seal
51 Stud
52 Hexagonnut
70, 71 Spring
74 Spring plate
75 Seal
76 Axialneedlebearing
77 Lock washer
79 Hexagonnut
80 Crossbeam
84 Washer
85 Seal
101, 102 Diaphragm case
103 Screw plug
104 Diaphragm stem
105 Diaphragm plate
106 Diaphragm washer
108 Diaphragm
111 Hexagonbolt
112 to 114 Hexagonnut
116 Washer
161 Lock pin
