Samsung ML-1630W User Manual

4.6 < Selecting and loading print media>
2 After inserting paper into the tray, while pinching the paper width
guide as shown, move it toward the stack of paper until it lightly
touches the side of the stack. Do not press the guide too tightly to
the edge of the paper; the guide may bend the paper.
Note
• Do not push the paper width guides far enough to cause the
materials to warp.
• If you do not adjust the paper width guides, it may cause paper
jams.
Setting the paper size and type
The settings you change remain in effect only while you are using the
current program. To make your changes permanent, make them in the
Printers folder.
Note
The following procedure is for Windows XP. For other Windows
OS, refer to the corresponding Windows User's Guide or online
help.
1 Click the Start button on the computer screen.
2 Select Printers and Faxes.
3 Right-click on the printer driver icon and select Printing
Preferences.
4 Click the Paper tab, and change the settings on Paper Options.
5 Click OK.

Samsung ML-1630W Specifications

General

Color	No
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	15 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Processor model	Samsung
Built-in processor	Yes
Maximum internal memory	- MB
Sound power level (standby)	26 dB
Sound pressure level (printing)	45 dB
Maximum duty cycle	5000 pages per month
Number of print cartridges	1
Maximum print size	216 x 356 mm
Media types supported	Thin, OHP, Thick
Paper tray media types	Bond paper, Labels, Plain paper, Recycled paper
Paper tray media weight	75 - 104 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	105 - 163 g/m²
Capacity cartridge	2000 sheets
Networking features	Fast Ethernet, WLAN
Wireless technology	802.11 b/g
Standard media sizes	105 x 148.5mm (4.1\
Compatible operating systems	Windows 2000/XP/2003 Server/Vista, Linux OS, Mac 10.3-10.4
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Total input capacity	100 sheets
Total output capacity	30 sheets
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	8 W
Power consumption (printing)	350 W
Display	-
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	190 x 558 x 395 mm
