Samsung ML-1630W User Manual

Using Smart Panel
23
5 Using Smart Panel
Smart Panel is a program that monitors and informs you of the
status of the printer, and allows you to customize the printer’s
settings.
Smart Panel is installed automatically when you
install the printer software.
N OTES :
• To use this program, you need:
- To check for Operating System(s) that are compatible with
your printer, refer to Printer Specifications in your Printer
User’s Guide.
- Mac OS X 10.3 or higher
- Linux. To check for Linux systems that are compatible with
your printer, refer to Printer Specifications in your Printer
User’s Guide.
- Internet Explorer version 5.0 or higher for flash animation
in HTML Help.
• If you need to know the exact name of your printer, you can
check the supplied CD-ROM.
Understanding Smart Panel
If an error occurs while printing, Smart Panel appears
automatically, showing the error.
You can also launch Smart Panel manually. Double-click the
Smart Panel icon on the Windows task bar (in Windows), or
Notification Area (in Linux). You can also click it on the status
bar (in Mac OS X).
Double-click this icon in Windows.
Click this icon in Mac OS X.
Click this icon in Linux.
If you are a Windows user, from the Start menu, select
Programs or All Programs → your printer driver name →
Smart Panel .
N OTES :
• If you have already installed more than one Samsung
printer, first select the printer model you want in order to
use the corresponding Smart Panel. Right-click (in Windows
or Linux) or click (in Mac OS X) the Smart Panel icon and
select
your printer name .
• The Smart Panel window and its contents shown in this
Software User’s Guide may differ depending on the printer or
Operating System in use.
The Smart Panel program displays the current status of the
printer, the level of toner remaining in the toner cartridge(s)
and various other information. You can also change settings.
Toner Level
You can view the level of toner remaining in the toner
cartridge(s). The printer and the number of toner cartridge(s)
shown in the above window may differ depending on the printer in
use. Any printers do not have this feature.
Buy Now
You can order replacement toner cartridge(s) online.
Troubleshooting Guide
You can view Help to solve problems.
Printer Setting
You can configure various printer settings in the Printer Settings
Utility window. Any printers do not have this feature.
N OTE : If your machine is connected a network, the
SyncThru Web Service window appears instead of the
Printer Settings Utility window. This program is supported in
Windows, MAC OS X. But in Linux, it is supported only in
certain software, such as Internet Explorer 5.5 or higher,
Safari 1.3 or higher, Mozilla FireFox 1.5 or higher.
1
1

Samsung ML-1630W Specifications

General

Color	No
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	15 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Processor model	Samsung
Built-in processor	Yes
Maximum internal memory	- MB
Sound power level (standby)	26 dB
Sound pressure level (printing)	45 dB
Maximum duty cycle	5000 pages per month
Number of print cartridges	1
Maximum print size	216 x 356 mm
Media types supported	Thin, OHP, Thick
Paper tray media types	Bond paper, Labels, Plain paper, Recycled paper
Paper tray media weight	75 - 104 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	105 - 163 g/m²
Capacity cartridge	2000 sheets
Networking features	Fast Ethernet, WLAN
Wireless technology	802.11 b/g
Standard media sizes	105 x 148.5mm (4.1\
Compatible operating systems	Windows 2000/XP/2003 Server/Vista, Linux OS, Mac 10.3-10.4
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Total input capacity	100 sheets
Total output capacity	30 sheets
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	8 W
Power consumption (printing)	350 W
Display	-
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	190 x 558 x 395 mm
