Samsung ML-1630W User Manual

Basic Printing
16
Extras Tab
You can select output options for your document. See “Printing
a Document” on page 12 for more information about accessing
the printer properties.
Click the Extras tab to access the following feature:
Watermark
You can create a background text image to be printed on each
page of your document.
For details, see “Using Watermarks” on
page 20.
Overlay
Overlays are often used to take the place of preprinted forms and
letterhead paper.
For details, see “Using Overlays” on page 21.
Output Options
• Print Subset : You can set the sequence in which the pages
print. Select the print order from the drop-down list.
- Normal (1,2,3) : Your printer prints all pages from the first
page to the last page.
- Reverse All Pages (3,2,1) : When you use this feature,
you do not need to sort the print-out by stacks.
- Print Odd Pages : Your printer prints only the odd numbered
pages of the document.
- Print Even Pages : Your printer prints only the even
numbered pages of the document.
• Reprint When Jammed : When this option is checked, the
printer retains the image of a printed page until the printer
signals that the page has successfully exited the printer.
About Tab
Use the About tab to display the copyright notice and the
version number of the driver. If you have an Internet browser,
you can connect to the Internet by clicking on the web site icon.
See “Printing a Document” on page 12 for more information
about accessing printer properties.
Printer Tab
If you access printer properties through the Printers folder,
you can view the
Printer tab. You can set the printer
configuration.
The following procedure is for Windows XP. For other Windows
OS, refer to the corresponding Windows User's Guide or online
help.
1 Click the Windows Start menu.
2 Select Printers and Faxes .
3 Select your printer driver icon.
4 Right-click on the printer driver icon and select
Properties .
5 Click the Printer tab and set the options.

Samsung ML-1630W Specifications

General

Color	No
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	15 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Processor model	Samsung
Built-in processor	Yes
Maximum internal memory	- MB
Sound power level (standby)	26 dB
Sound pressure level (printing)	45 dB
Maximum duty cycle	5000 pages per month
Number of print cartridges	1
Maximum print size	216 x 356 mm
Media types supported	Thin, OHP, Thick
Paper tray media types	Bond paper, Labels, Plain paper, Recycled paper
Paper tray media weight	75 - 104 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	105 - 163 g/m²
Capacity cartridge	2000 sheets
Networking features	Fast Ethernet, WLAN
Wireless technology	802.11 b/g
Standard media sizes	105 x 148.5mm (4.1\
Compatible operating systems	Windows 2000/XP/2003 Server/Vista, Linux OS, Mac 10.3-10.4
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Total input capacity	100 sheets
Total output capacity	30 sheets
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	8 W
Power consumption (printing)	350 W
Display	-
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	190 x 558 x 395 mm
