Using Your Printer with a Macintosh
31
7 Using Your Printer with
a Macintosh
Your printer supports Macintosh systems with a built-in USB
interface or 10/100 Base-TX network interface card. When you
print a file from a Macintosh computer, you can use the CUPS driver
by installing the PPD file.
N OTE : Some printers do not support a network
interface. Make sure that your printer supports a
network interface by referring to Printer Specifications
in your Printer User’s Guide.
This chapter includes:
• Installing Software
• Uninstalling software
• Using SetIP program
• Setting Up the Printer
•Printing
Installing Software
The CD-ROM that came with your printer provides you with the
PPD file that allows you to use the CUPS driver or Apple
LaserWriter driver
(only available when you use a printer
which supports the PostScript driver)
, for printing on a
Macintosh computer.
Installing the Printer driver
1 Make sure that you connect your printer to the computer.
Turn on your computer and printer.
2 Insert the CD-ROM which came with your printer into the
CD-ROM drive.
3 Double-click CD-ROM icon that appears on your
Macintosh desktop.
4 Double-click the MAC_Installer folder.
5 Double-click the Installer icon.
6 Enter the password and click OK .
7 The Samsung Installer window opens. Click Continue
8 Select Easy Install and click Install . Easy Install is
recommended for most users. All components necessary
for printer operations will be installed.
If you select
Custom Install , you can choose individual
components to install.
9 The message which warns all application will close on your
computer appears, Click
Continue .
10 Select Typical installation for a local printer and then
click
OK .
N OTE : If you select Typical installation for a network
printer
, see “Using SetIP program” on page 32 after the
installation is finished.
11 After the installation is finished, click Quit .
N OTE : After the installation is finished, see “Setting Up the
Printer” on page 32
Uninstalling software
Uninstall is required if you are upgrading the software, or if
installation fails.
1 Make sure that you connect your printer to the computer.
Turn on your computer and printer.
2 Insert the CD-ROM which came with your printer into the
CD-ROM drive.
3 Double-click CD-ROM icon that appears on your
Macintosh desktop.
4 Double-click the MAC_Installer folder.
5 Double-click the Installer icon.
6 Enter the password and click OK .
7 The Samsung Installer window opens. Click Continue
8 Select Uninstall and click Uninstall .
9 When the uninstallation is done, click Quit .

Samsung ML-1630W Specifications

General

Color	No
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	15 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Processor model	Samsung
Built-in processor	Yes
Maximum internal memory	- MB
Sound power level (standby)	26 dB
Sound pressure level (printing)	45 dB
Maximum duty cycle	5000 pages per month
Number of print cartridges	1
Maximum print size	216 x 356 mm
Media types supported	Thin, OHP, Thick
Paper tray media types	Bond paper, Labels, Plain paper, Recycled paper
Paper tray media weight	75 - 104 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	105 - 163 g/m²
Capacity cartridge	2000 sheets
Networking features	Fast Ethernet, WLAN
Wireless technology	802.11 b/g
Standard media sizes	105 x 148.5mm (4.1\
Compatible operating systems	Windows 2000/XP/2003 Server/Vista, Linux OS, Mac 10.3-10.4
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Total input capacity	100 sheets
Total output capacity	30 sheets
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	8 W
Power consumption (printing)	350 W
Display	-
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	190 x 558 x 395 mm
