Samsung ML-1630W User Manual

Installing Printer Software in Windows
11
Reinstalling Printer Software
You can reinstall the software if installation fails.
1 Start Windows.
2 From the Start menu select Programs or All Programs
→ your printer driver name → Maintenance .
3 Select Repair and click Next .
4 The list of printers available on the network appears.
Select the printer you want to install from the list and then
click
Next .
• If you do not see your printer on the list, click
Update to
refresh the list, or select
Add TCP/IP Port to add your
printer to the network. To add the printer to the
network, enter the port name and the IP address for the
printer.
• To find a shared network printer (UNC Path), select
Shared Printer [UNC] and enter the shared name
manually or find a shared printer by clicking the
Browse
button.
You will see a component list so that you can reinstall any
item individually.
NOTE : If your printer is not already connected to the
computer, the following window will appear.
• After connecting the printer, click Next .
• If you don’t want to connect the printer at this time, click
Next , and No on the following screen. Then the installation
will start and a test page will not be printed at the end of the
installation.
• The reinstallation window that appears in this User’s
Guide may differ depending on the printer and
interface in use.
5 Select the components you want to reinstall and click
Next .
If you installed the printer software for local printing
and
you select your printer driver name , the window
asking you to print a test page appears. Do as follows:
a. To print a test page, select the check box and click
Next .
b. If the test page prints out correctly, click Yes .
If it doesn’t, click
No to reprint it.
6 When the reinstallation is done, click Finish .
Removing Printer Software
1 Start Windows.
2 From the Start menu select Programs or All Programs
→ your printer driver name → Maintenance .
3 Select Remove and click Next .
You will see a component list so that you can remove any
item individually.
4 Select the components you want to remove and then click
Next .
5 When your computer asks you to confirm your selection,
click
Yes .
The selected driver and all of its components are removed
from your computer.
6 After the software is removed, click Finish .

Samsung ML-1630W Specifications

General

Color	No
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	15 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Processor model	Samsung
Built-in processor	Yes
Maximum internal memory	- MB
Sound power level (standby)	26 dB
Sound pressure level (printing)	45 dB
Maximum duty cycle	5000 pages per month
Number of print cartridges	1
Maximum print size	216 x 356 mm
Media types supported	Thin, OHP, Thick
Paper tray media types	Bond paper, Labels, Plain paper, Recycled paper
Paper tray media weight	75 - 104 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	105 - 163 g/m²
Capacity cartridge	2000 sheets
Networking features	Fast Ethernet, WLAN
Wireless technology	802.11 b/g
Standard media sizes	105 x 148.5mm (4.1\
Compatible operating systems	Windows 2000/XP/2003 Server/Vista, Linux OS, Mac 10.3-10.4
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Total input capacity	100 sheets
Total output capacity	30 sheets
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	8 W
Power consumption (printing)	350 W
Display	-
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	190 x 558 x 395 mm
