Samsung ML-1630W User Manual

Installing Printer Software in Windows
5
4 Select Typical installation for a local printer . Click
Next .
NOTE : If your printer is not already connected to the
computer, the following window will appear.
• After connecting the printer, click
Next .
• If you don’t want to connect the printer at this time, click
Next , and No on the following screen. Then the installation
will start and a test page will not be printed at the end of the
installation.
• The installation window that appears in this User’s
Guide may differ depending on the printer and
interface in use.
5 After the installation is finished, a window asking you to
print a test page appears. If you choose to print a test
page, select the checkbox and click Next .
Otherwise, just click Next and skip to step 7.
6 If the test page prints out correctly, click Yes .
If not, click
No to reprint it.
7 To register yourself as a user of Samsung Printers in order
to receive information from Samsung, select the checkbox
and click Finish . You are now sent to the Samsung web
site.
Otherwise, just click
Finish .
NOTE : After setup is complete, if your printer driver doesn’t
work properly, reinstall the printer driver. See “Reinstalling
Printer Software” on page 11.
Custom Installation
You can choose individual components to install.
1 Make sure that the printer is connected to your computer
and powered on.
2 Insert the supplied CD-ROM into your CD-ROM drive.
The CD-ROM should automatically run, and an installation
window appears.
If the installation window does not appear, click
Start and
then
Run . Type X:\Setup.exe , replacing “ X ” with the
letter which represents your drive and click
OK .
If you use Windows Vista, click Start → All programs →
Accessories → Run , and type X:\Setup.exe .
If the
AutoPlay window appears in Windows Vista, click
Run Setup.exe in Install or run program field, and
click
Continue in the User Account Control window.

Samsung ML-1630W Specifications

General

Color	No
Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	15 s
Print speed (black, normal quality, A4/US Letter)	16 ppm
Processor model	Samsung
Built-in processor	Yes
Maximum internal memory	- MB
Sound power level (standby)	26 dB
Sound pressure level (printing)	45 dB
Maximum duty cycle	5000 pages per month
Number of print cartridges	1
Maximum print size	216 x 356 mm
Media types supported	Thin, OHP, Thick
Paper tray media types	Bond paper, Labels, Plain paper, Recycled paper
Paper tray media weight	75 - 104 g/m²
Non-ISO print media sizes	Executive (184 x 267mm), Letter (media size)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	105 - 163 g/m²
Capacity cartridge	2000 sheets
Networking features	Fast Ethernet, WLAN
Wireless technology	802.11 b/g
Standard media sizes	105 x 148.5mm (4.1\
Compatible operating systems	Windows 2000/XP/2003 Server/Vista, Linux OS, Mac 10.3-10.4
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Total input capacity	100 sheets
Total output capacity	30 sheets
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	8 W
Power consumption (printing)	350 W
Display	-
Standard interfaces	USB 2.0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Dimensions (WxDxH)	190 x 558 x 395 mm
