Specifications 153
Specifications
System Specification
The system specifications will be described below. The system specifications may
differ depending on the derived models.
The system specifications are subject to change without notice. For detailed system specifications, refer to the product
catalog.
The capacity of the hard disk drive with Samsung Recovery Solution will be displayed as less than the specified
capacity.
Item Specification Remarks
CPU Intel Core ™ processor Duo
Intel Core ™ processor Solo
Intel Celeron M
Optional
Cache memory 2MB / 1MB (Celeron M)
Main memory 256~2GB, Max 4GB, Memory type : DDR2 SODIMM Optional
Main Chipset Intel i945PM / i945GM Optional
Hard disk drive (HDD) 9.5mmH 2.5" HDD
40~120GB
Optional
CD drive RW-Combo, DVD Super Multi Optional
Graphics NVIDIA Geforce Go 7600/7400 (TurboCache 256MB)
Intel GMA 950 (DVMT Max 128MB)
Optional
Sound High Definition Audio Codec AD1986A
Network Interface Modem: V.92
Wired LAN: Broadcom BCM4401E 10/100
Wireless LAN: 802.11ABG
Bluetooth 2.0+EDR
Optional
Optional
Optional
Optional
Multi Card Slot Memory Stick, Memory Stick Pro, SD Card, MMC, xD card Supported
PC Card Slot PCMCIA Type I and, II Compatible
Ports IEEE 1394 (6 Pin), USB 2.0 x 4, Microphone, Headphone(S/PDIF
supported), Modem(RJ-11), LAN(RJ-45), Monitor and TV Out(S-Video),
DC Jack, Security Lock Port
Optional
Dimensions (mm) 357 x 262 x 33.9~36.6 W x D x H
LCD 15.4" WXGA (1280 x 800)
15.4" WSXGA+ (1680 x 1050)
Optional
Weight 2.71~2.73Kg Optional
Battery Lithium-Ion smart battery: 6 cells or 9 cells Optional
Operation
Environment
Temperature (storage) : -5 ~ 40°C (operation) : 10 ~ 32° C
Humidity (storage) : 5% ~ 90% (operation) : 20% ~ 80%
Operation Voltage 100 - 240 VAC
Frequency 50 - 60 Hz
Output Power 60/90W Optional
Output Voltage 19.0VDC
