76 Users Manual
2. Select an icon that represents the corresponding location from the Saved Locations
window and then click Move.
3. When the network settings of the selected location are applied, the new location
and the network connection information are displayed in The detailed
Information for window.
Sharing Internet Access
This section describes the procedures to share Internet Access.
To share Internet Access, you first have to set a sharing server and a sharing client.
When the setup is complete, you can access the Internet from the sharing client by
connecting to the sharing server.
Sharing Server : A computer with a direct connection to the internet and a
local network connection.
Sharing Client : A computer that uses the Internet by connecting to a sharing
server without itself having a direct connection to the Internet.
You can connect a sharing server and a sharing client as follows.(See Figure
5 on page (p73))
For Connection 3, you have to connect a LAN card in advance.
To connect a sharing server and a sharing client using a wired LAN, connect
the computers with a crossover LAN cable or network hub first.
To use a wireless LAN, press the <Fn> and <F8> key combination
simultaneously to enable a wireless LAN.
When the wireless LAN is turned on, the Wireless LAN Operation LED ( )
lights up.
As an example, Internet sharing procedures for [Connection 1], which connect the
sharing server and the Internet through a wired LAN and connect the sharing server and
the sharing client through a wireless LAN, are described below.
Sharing Server Sharing Client
External Internet Device Client Device
Connection 1 Wired LAN Wireless LAN Connect a sharing client with the
Connection 2 Wireless LAN Wired LAN device that is the same as the
Connection 3 Wired LAN Wired LAN client device of the sharing server.
To Next Page
