Getting Started 15
Reading the Status Indicators
Shows the operating status of the computer.
Num Lock Turns on when the numeric keypad is activated.
Caps Lock Turns on when all alphabet characters you type will be in upper case.
Scroll Lock Turns on when it is set to scroll the screen up and down while the cursor
position does not change in some applications.
Hard Disk Drive /
CD-ROM Drive
Blinks when the hard disk drive or CD-ROM drive is in operation.
Wireless LAN Turns on when the wireless LAN function is enabled. (This light does not
operate for models without a wireless LAN.)
Battery Turns Light Green - when the battery is fully charged, or when the battery is
not installed.
Turns amber - when the battery is being charged.
Blinks - when the battery is not properly installed.
Power Turned On - when the computer is turned on.
Blinks - when the computer is in Standby mode.
