Samsung NX5 User Manual

14
Title and role of each part
Mode dial (p. 5)
AF-assist light
/timer lamp (p. 61)
Power switch (p. 23)
Lens mount index
(p. 21)
Hot-shoe
cover
(p. 58)
Strap holder
(p. 22)
Built-in flash
(p. 55)
Dial (p. 26)
Shutter button (p. 7)
Lens removal
button (p. 21)
Lens mount (p. 21)
Flash button
(p. 55)
Depth preview button
(p. 37)
Hot-shoe (p. 58)
Green button*
Drive mode button (p. 73)
Diopter adjustment
dial (p. 16)
* Use the green button [ ].
The following setup values are initialized if the button is pushed once in the standby state
for shooting.
Program shift / Detailed setup of picture wizard / Fine tuning of white balance / Color Temp.
setting value / Adjusting the colors of screen menu / Timer / Flash EV / When selecting or setting
AF, shift the changed focus area to the center / Bracketing setup
Body cap (p. 21)
DC-IN port
HDMI port (p. 92)
Shutter release
connection port
USB/AV OUT Port
(p. 94)
Image Sensor

Samsung NX5 Specifications

General

Sensor type	CMOS
