16
Title and role of each part
Diopter adjustment dial/Eye-cup/
Status lamp
Use of Diopter adjustment dial
It is possible to adjust the
viewfinder appropriate for the
eyesight of user.
If the image is not shown clearly
through the viewfinder, move
the eyesight adjustment dial in
the left/right direction to have a
clear view.
Eye-cup
Removal of Eye-cup
When the camera is shipped,
the eyecup is attached to the
viewfinder. Push the Eye-cup
up as shown in the figure for
removal.
Eyesight
adjustment dial
Status lamp
In the case of saving a picture or
shooting a movie, this shows the
operating status of the camera by
blinking the status indicator lamp
• Blinking: When saving photos,
recording movies, being read by
a computer or printer.
• Steady: When there is no data
transfer or when connecting to a
computer or printer is complete.
Status lamp
