Samsung The Frame User Manual

Setting up Art mode
In Art mode, use the directional buttons on the remote control to move to the Settings menu item at the
bottom. You can adjust the following functions:
 Brightness
Use the directional buttons on the remote control to move to Modify at the top, and then press the Select
button. In the next screen, adjust the picture brightness. After selecting the desired settings, press the
Select button on the remote control.
– To immediately set Brightness while enjoying Art mode, press the button on the remote control.
 Sleep After
If no motion is detected around the TV for the set time, the TV turns off automatically. Use the directional
buttons on the remote control to move to the top items. After selecting the desired time, press the Select
button on the remote control.
 Motion Detector
The sensitivity of the motion detector function can be adjusted. Use the directional buttons on the remote
control to move to the top items. After selecting the desired sensitivity, press the Select button on the
remote control.
 Night Mode
When this function is turned on, the TV turns off automatically if no light is detected around the TV. Use the
directional buttons on the remote control to move to the top items, and then turn this function on or off.
Remove images from My Collection
You can remove the saved images from My Collection.
1. Use the directional buttons on the remote control to move to My Collection.
2. Use the directional buttons on the remote control to move to Favourites or My Photos.
3. Use the directional buttons on the remote control to move to Options+ at the top of the screen.
4. Move the focus to Remove, and then press the Select button on the remote control.
5. Use the directional buttons on the remote control to move to an image, and then press the Select button.
– You can select multiple images.
6. Use the directional buttons on the remote control to move to Remove Selected at the top of the screen,
and then press the Select button.
English - 17
English

Samsung The Frame Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	43 \
Display brightness	- cd/m²
Display technology	LED
Display diagonal (metric)	108 cm
Motion interpolation technology	PQI (Picture Quality Index) 1800
3D	No
Languages support	BUL, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LAT, LIT, NOR, POL, POR, RUM, SER, SLK, SLV, SWE
Annual energy consumption	132 kWh
Audio decoders	DTS, Dolby Digital Plus
RMS rated power	20 W
Number of speakers	-
Tuner type	Analog & digital
Digital signal format system	DVB-C, DVB-S2, DVB-T2 HD
HDMI ports quantity	4
DVI-D ports quantity	0
USB 2.0 ports quantity	3
Ethernet LAN (RJ-45) ports	1
Consumer Electronics Control (CEC)	Anynet+
Common interface Plus (CI+) version	1.4
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	95 W
Product color	Black
Mercury content	0 mg
Heavy metals free	Hg (mercury)
Panel mounting interface	200 x 200 mm
Package depth	235 mm
Package width	1104 mm
Package height	694 mm
Package weight	21900 g
Video formats supported	H.264 BP, H.265, HEVC, M-JPEG, MPEG1, MPEG2, MPEG4-ASP, MPEG4-SP, MVC
Picture processing technology	Samsung Ultra Clean View

Weight and Dimensions

Depth (with stand)	200 mm
Width (with stand)	996.6 mm
Height (with stand)	599.8 mm
Weight (with stand)	11700 g
Depth (without stand)	42.5 mm
Width (without stand)	966.6 mm
Height (without stand)	555.3 mm
Weight (without stand)	11200 g
