Video Apps problems (Youtube etc)
Change the DNS to 8.8.8.8. Select > Settings > General > Network > Network Status > IP Settings >
DNS setting > Enter manually > DNS Server > enter 8.8.8.8 > OK.
Reset by selecting > Settings > Support > Device Care > Self Diagnosis > Reset Smart Hub.
The TV remains on or does not turn on automatically.
If the surrounding area is too dark or bright, the motion sensor may not work normally. The performance
of the motion sensor may be affected by the installation environment (height, tilt, obstacles). If the clothes
you wear or your skin colour is similar to the surrounding shading, the motion sensor may not work properly.
The TV responds to all visual changes around it (lights, displays, dogs, out-of-window changes, and other
occurrences). You can adjust the response level by adjusting the sensitivity of the motion detector.
(
> Art > Settings > Motion Detector)
Precautions when using Art mode
The motion sensor is located at the bottom of the TV. Do not block the sensor at the front of the TV. The
motion sensor as well as the brightness and colour tone of the screen can be affected.
Art mode uses algorithms to minimise image burn-in that can be caused by displaying still images on the
screen for long periods of time.
The performance of the sensor may vary depending on the TV installation and operating environment.
The screen brightness and colour tone may be affected depending on the colour of the floor on which
the TV stands.
In an environment where special light sources other than standard light sources (halogen, fluorescent)
are used, the sensor's motion recognition performance may vary depending on the positions, types, and
number of the light sources.
If the area around the TV is too dark or bright, the screen brightness may be limited or the sensor may
not work normally.
If the TV is installed too high or too low, the sensor may not work normally.
The motion sensor may sense motion from a flashing LED, a pet, a car moving outside the window, or
other occurrence and start operating.
Depending on the Auto Power Off ( > Settings > General > Eco Solution > Auto Power Off) function
settings, the TV may turn off when there is no user input in Art mode, such as inputs from the remote
control.
> Settings > General > System Manager > Time > Sleep Timer and Off Timer function does not work in
Art mode.
> Settings > General > System Manager > Auto Protection Time function does not work in Art mode.
English - 26

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Samsung The Frame and is the answer not in the manual?

Samsung The Frame Specifications

General IconGeneral
Screen shapeFlat
Response time- ms
Display diagonal43 \
Display brightness- cd/m²
Display technologyLED
Display diagonal (metric)108 cm
Motion interpolation technologyPQI (Picture Quality Index) 1800
3DNo
Languages supportBUL, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LAT, LIT, NOR, POL, POR, RUM, SER, SLK, SLV, SWE
Annual energy consumption132 kWh
Audio decodersDTS, Dolby Digital Plus
RMS rated power20 W
Number of speakers-
Tuner typeAnalog & digital
Digital signal format systemDVB-C, DVB-S2, DVB-T2 HD
HDMI ports quantity4
DVI-D ports quantity0
USB 2.0 ports quantity3
Ethernet LAN (RJ-45) ports1
Consumer Electronics Control (CEC)Anynet+
Common interface Plus (CI+) version1.4
AC input voltage220 - 240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.5 W
Power consumption (typical)95 W
Product colorBlack
Mercury content0 mg
Heavy metals freeHg (mercury)
Panel mounting interface200 x 200 mm
Package depth235 mm
Package width1104 mm
Package height694 mm
Package weight21900 g
Video formats supportedH.264 BP, H.265, HEVC, M-JPEG, MPEG1, MPEG2, MPEG4-ASP, MPEG4-SP, MVC
Picture processing technologySamsung Ultra Clean View
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)200 mm
Width (with stand)996.6 mm
Height (with stand)599.8 mm
Weight (with stand)11700 g
Depth (without stand)42.5 mm
Width (without stand)966.6 mm
Height (without stand)555.3 mm
Weight (without stand)11200 g
