Samsung The Frame User Manual

Before Reading This User Manual ---------------------------------------------------------------------------- 2
Warning! Important Safety Instructions
---------------------------------------------------------------------------- 3
01 What's in the Box?
02 Connecting the TV to the One Connect
03 TV Installation
Mounting the TV on a wall ---------------------------------------------------------------------------- 9
Providing proper ventilation for your TV
---------------------------------------------------------------------------- 10
Safety Precaution: Securing the TV to the wall to
prevent falling
---------------------------------------------------------------------------- 11
Precautions when installing the TV with a stand
---------------------------------------------------------------------------- 12
04 Using Art Mode
Viewing images ---------------------------------------------------------------------------- 14
Setting the style of the selected image
---------------------------------------------------------------------------- 16
Setting up Art mode
---------------------------------------------------------------------------- 17
Using Art mode with the SmartThings app
---------------------------------------------------------------------------- 18
05 The Samsung Smart Remote
About the Buttons on the Samsung Smart Remote ---------------------------------------------------------------------------- 19
Pairing the TV to the Samsung Smart Remote
---------------------------------------------------------------------------- 20
Installing batteries into the Samsung Smart Remote
---------------------------------------------------------------------------- 20
06 Running the Initial Setup
Using the TV Controller ---------------------------------------------------------------------------- 22
07 Connecting to a Network
Network Connection - Wireless ---------------------------------------------------------------------------- 23
Network Connection - Wired
---------------------------------------------------------------------------- 23
08 Troubleshooting and Maintenance
Troubleshooting ---------------------------------------------------------------------------- 24
Precautions when using Art mode
---------------------------------------------------------------------------- 26
What is Remote Support?
---------------------------------------------------------------------------- 27
Eco Sensor and screen brightness
---------------------------------------------------------------------------- 27
Caring for the TV
---------------------------------------------------------------------------- 28
09 Specifications and Other Information
Specifications ---------------------------------------------------------------------------- 29
Environmental Considerations
---------------------------------------------------------------------------- 30
Decreasing power consumption
---------------------------------------------------------------------------- 30
Licences
---------------------------------------------------------------------------- 30
English - 5
English
Contents

Samsung The Frame Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	43 \
Display brightness	- cd/m²
Display technology	LED
Display diagonal (metric)	108 cm
Motion interpolation technology	PQI (Picture Quality Index) 1800
3D	No
Languages support	BUL, CZE, DAN, DEU, DUT, ENG, ESP, EST, FIN, FRE, GRE, HUN, ITA, LAT, LIT, NOR, POL, POR, RUM, SER, SLK, SLV, SWE
Annual energy consumption	132 kWh
Audio decoders	DTS, Dolby Digital Plus
RMS rated power	20 W
Number of speakers	-
Tuner type	Analog & digital
Digital signal format system	DVB-C, DVB-S2, DVB-T2 HD
HDMI ports quantity	4
DVI-D ports quantity	0
USB 2.0 ports quantity	3
Ethernet LAN (RJ-45) ports	1
Consumer Electronics Control (CEC)	Anynet+
Common interface Plus (CI+) version	1.4
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	95 W
Product color	Black
Mercury content	0 mg
Heavy metals free	Hg (mercury)
Panel mounting interface	200 x 200 mm
Package depth	235 mm
Package width	1104 mm
Package height	694 mm
Package weight	21900 g
Video formats supported	H.264 BP, H.265, HEVC, M-JPEG, MPEG1, MPEG2, MPEG4-ASP, MPEG4-SP, MVC
Picture processing technology	Samsung Ultra Clean View

Weight and Dimensions

Depth (with stand)	200 mm
Width (with stand)	996.6 mm
Height (with stand)	599.8 mm
Weight (with stand)	11700 g
Depth (without stand)	42.5 mm
Width (without stand)	966.6 mm
Height (without stand)	555.3 mm
Weight (without stand)	11200 g
