Sanyo PLC-XU75 Service Manual

-21-
● : Adjustment necessary ❍ : Check necessary
Adjustments after Parts Replacement
Adjustments
Disassembly / Replaced Parts
LCD/
Prism Ass’y
Integrator
Lens (OUT)
Relay
Lens (OUT)
Polarized Glass
Power Board Main Board
R G B
Optical Adjustments
Contrast Adjustment
R-Contrast adjustment
●
G-Contrast adjustment
●
B-Contrast adjustment
●
Integrator lens adjustment
❍ ●
Relay lens-out adjustment
❍ ●
Electrical Adjustments
Panel type check and setting
● ●
Fan control adjustment
● ●
Auto-calibration [PC]
●
Auto-calibration [Component]
●
Auto-calibration [Video]
●
Common center adjustment
● ●
50% white adjustment [PC]
● ●
White balance adjustment [PC]
❍ ❍
50% white adjustment [Video]
● ●
White balance adjustment [Video]
❍ ❍
White uniformity adjustment
❍ ❍
