KH3-XU7800, KZ3-XU7500

-89-

Mechanical Parts List

FOR KH3-XU7800

CABINET PARTS

C01 610 334 6236 ASSY,STAND-KH3AC

C02 610 337 7766 CABINET TOP SERVICE-KH3AC

(Including Key No. C02-1 and C02-2)

C02-1 610 334 1897 BUTTON-KH3AC

C02-2 610 334 8087 DEC INLAY LED-KH3AC

C03 610 334 1804 CABINET BOTTOM-KH3AC

C04 910 325 2859 CAP LENS-PT5EC

C05 610 336 9198 COVER LAMP SERVICE-KH3AC

C06 610 334 8117 DEC INLAY RC-KH3AC

C07 910 325 2477 DEC LEG-PT5EC

C08 610 335 4910 FILTER BASE B-KH3AC

C09 610 334 8100 FILTER F-KH3AC

C10 610 334 1835 PANEL AV-KH3AC

C11 945 047 8032 BADGE,SANYO*26.2X5.7L26.0

CHASSIS PARTS

M01 610 334 8025 MTG DUCT PANEL TOP-KH3AC

M02 610 334 8285 MTG DUCT PANEL BTM-KH3AC

M03 610 334 8162 MTG DUCT LAMP TOP-KH3AC

M04 610 334 8001 MTG DUCT LAMP BTM-KH3AC

M05 610 334 8476 MTG LAMP FAN-KH3AC

M06 610 334 8032 MTG MICROSWITCH-KH3AC

M07 910 321 7810 OPTICAL BASE BTM-MT5A

M08 910 321 7896 OPTICAL BASE TOP A-MT5A

M09 910 321 7780 OPTICAL BASE TOP B-MT5A

SCREWS

S01 411 189 8600 SCR BIN 3X8

S02 412 076 0806 SPECIAL SCREW

S03 411 189 6507 BOLT HEX-SCT+SW+W 2.5X5

S04 312 069 7105 SPECIAL SCREW V

OPTICAL PARTS

L01 610 336 7897 ASSY,LCD PNL/PSM -KH3AC

(Including Key No. L01-1 to L01-5 and LCD Panels)

L01-1 945 077 8354 POLARIZED GLASS(OUT/R)

L01-2 945 087 1185 POLARIZED GLASS(OUT/G)

L01-3 945 082 0824 POLARIZED GLASS(OUT/B)

L01-4 945 077 8385 PRE-POLARIZED GLASS

L01-5 945 083 6597 PRE-POLARIZED GLASS

L02 945 078 0692 LENS,INTEGRATOR(IN)

L03 945 078 0708 LENS,INTEGRATOR(OUT)

L04 945 078 0722 LENS,CONDENSER(OUT)

L05 945 078 0739 LENS,CONDENSER(G)

L06 945 078 0753 LENS,RELAY(OUT)

L07 945 078 0760 LENS,CONDENSER(R)

L08 945 078 4140 LENS,PROJECTION

L09 945 087 1154 LENS,CONDENSER(B)

L10 945 081 7640 MIRROR(B)

L11 945 081 7657 MIRROR(R)

L12 945 078 0845 PRISM(PBS)

L13 945 077 8347 POLARIZED GLASS(IN/R)

L14 945 087 1178 POLARIZED GLASS(IN/G)

L15 945 083 3886 POLARIZED GLASS(IN/B)

L16 945 085 0043 DICHROIC MIRROR (B)

L17 945 078 0784 DAICHROIC MIRROR(G)

FOR KZ3-XU7500
