KH3-XU7800, KZ3-XU7500
-65-
Electrical Parts List
Electrical Parts Location
● Out Of Circuit Board
Main Board
● Assemblied Boards
FN906
Cooling Fan
Filter Board
A901
Ballast Board
R/C Board
FN902
Cooling Fan
LP900
Lamp Ass’y
Power Board
FN901
Cooling Fan
SP901
Speaker
FN903
Cooling Fan
FN904
Cooling Fan
FN905
Cooling Fan
SW901
Lamp Cover
Switch
SW902
Thermal Switch
