Sanyo PLV-Z700 Service Manual

PCB_MF4A A9
■ Printed Wiring Board Diagrams
This projector is isolated from AC line by using the internal converter transformer.
Please pay attention to the following notes in servicing
1. Do not touch the part on hot side (primary circuit) or both parts on hot and cold sides
(secondary circuit) at the same time.
2. Do not shorten the circuit between hot and cold sides.
3. The grounding lead must be connected to the ground of the same circuit when measuring
of voltages and waveforms.
! CAUTION
FILTER (SIDE : A)
TYPE: 215005 T5AH250V
(LIVE)
1AA4B10C5980A
PARTS_SIDE
? ? ?
* * *
F601
1
2
3
R611
L611
C611
L612
C612
C613
K6A
K601
VA612
VA613
C614
C616
C617
C618
VA611
SW601
A30C5
FILTER (SIDE : B)
SOLDER_SIDE
F601
3
2
1
R611
L611
C611
L612
C612
C613
K6A
K601
VA612
VA613
C614
C616
C617
C618
VA611
SW601
A30C5
POWER
“CN101”
DOOR SW_1 (SIDE : A)
DOOR SW_1 (SIDE : B)
1AA4B10C5980B
PARTS_SIDE
??? ***
1
3
K8801
SW8801
A30C5
SOLDER_SIDE
3 1
K8801
SW8801
A30C5
MAIN
“K8M”
DOOR SW_2 (SIDE : A)
1AA4B10C5980C
PARTS_SIDE
???
***
SW8811
1
3
K8811
A30C5
MAIN
“K8L”
DOOR SW_2 (SIDE : B)
SOLDER_SIDE
SW8811
3
1
K8811
A30C5

Sanyo PLV-Z700 Specifications

General

Projection technology	LCD
Contrast ratio (typical)	-
Resolution	1920 x 1080 pixels
Aspect ratio	16:9
RS-232 ports	1
Dimensions (WxDxH)	400 x 346 x 154 mm
Lamp type	UHP
Lamp power	165 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Serial interface type	RS-232
Component video (YPbPr/YCbCr) in	2

Weight and Dimensions

Weight	7500 g
