- 88 -
■ Control Port Functions
● I/O Port Table of Main CPU (IC301, PW392)
Pin No. Name Function Name Function I/O
2 S3.3V S3.3VPWA -
20 S3.3V S3.3VPW -
238 SIDEN I
337 SIEVNODD I
238 SICLK I
18 SIAHS I
133 SIHS I
240 SIVS I
244 DOOR SHUTTER_DEMO Door_Open/Close demo I
342 DOOR DOOR_OPEN_SENS Door open sensor I
22 DOOR DOOR_CLOSE SENS Door close sensor I
343 LED STANDBY_LED STANDBY LED Drive, On : H O
23 LED WARNING_LED WARNING LED Drive, On : H O
137 LED POWER_LED POWER LED Drive, On : H O
245 LED LAMP_LED LAMP LED Drive, On : H O
139 DOOR DOOR_OPEN O
246 DOOR DOOR_CLOSE O
345 BALLAST_ON_SW Lamp control, Lamp On : H O
25 POWER_ON_SW Power Control Switch O
140 15V 15V_SW O
247 1.8V 1.8V_SW O
346 3.3V 3.3V_SW O
437 FAN FAN_SW Fan Control Switch O
248 NCONFIG O
142 NSTATUS O
27 CONF_DONE O
249 IRIS IRIS_ERR_OUT Lamp IRIS Control I
143 IRIS IRIS_PWR_ON Lamp IRIS Control O
28 DDC PCDDCSEL O
250 HDMI1 R1HPDOUT O
251 SIRST O
29 HDMI2 HDMI2DCT I
144 HDMI1 HDMI1DCT I
145 HDMI2 R2DDCSEL O
146 SCART_CV_SW O
32 HDMI2 R2HPDOUT O
33 HDMI1 R1DDCSEL O
438 KEY KEY11 Key Control Output O
349 KEY KEY21 Key Control Output O
252 KEY KEY31 Key Control Output O
147 GAMMA_RESET O
34 -6V -6V_SW O
439 THERM_DETECT I
253 KEY KEY01 Key Control Input I
148 KEY KEY02 Key Control Input I
35 KEY KEY03 Key Control Input I
350 POWER_SW_ON I
36 P_FAIL PFAIL_DETECT O
149 SERIAL_EN O
37 FPG_K1 O
To Next Page
