Sanyo PLV-Z700 Service Manual

- 78 -
FN901 FN902 FN903 FN904 FN905
1 2
IC301
SYSTEM
CONTROL
IC4401
COLOR
MANAGER
MAIN BOARD
Power-On : H
IC4801
SUB CPU
437
176
65
66
177
FAN3
FAN4
FAN5
FAN2
FAN1
IC8841
TEMP.
SENSOR
K78E
1 2
K78D
1 2
K78C
1 2
K78B
1 2
K78A
FAN_SW
FAN_SW FAN_CTL3
FAN_CTL2
FAN_CTL1
FAN_CTL0
Q7821
Q7831
IC7801
IC7802
IC7861
Q7841
Q7851
IC7891
IC7891 IC7891 IC7891
IC7891
FAN_MTR1-5
FAN_MTR1
FAN_MTR2
FAN_MTR3
FAN_MTR4
FAN_MTR5
TPFAN1
TPFAN2
TPFAN3
TPFAN4
TPFAN5
K8E
K8F 291
343
292
344
293
FAN_CTL0
FAN_CTL1
FAN_CTL2
FAN_CTL3
S16VF
68
439
281
THERM2
THERM_DET
THERM1
TH901
TH902
31 3 31
FAN_SW
● Fan control circuit
FAN(FN905)
FAN(FN904)
FAN(FN902)
FAN(FN903)
FAN(FN901)
THERMAL SWITCH(SW902)
DOOR MOTOR
TEMP. SENSOR IC(IC8841)_SiIDE-B
THERMISTOR(TH902)
FRONT
● Fan and sensor location
Chassis Block Diagrams
THERMISTOR(TH901)
MAIN BOARD

Sanyo PLV-Z700 Specifications

General

Projection technology	LCD
Contrast ratio (typical)	-
Resolution	1920 x 1080 pixels
Aspect ratio	16:9
RS-232 ports	1
Dimensions (WxDxH)	400 x 346 x 154 mm
Lamp type	UHP
Lamp power	165 W
Light source type	Lamp
Service life of light source	2000 h
Service life of light source (economic mode)	3000 h
Serial interface type	RS-232
Component video (YPbPr/YCbCr) in	2

Weight and Dimensions

Weight	7500 g
