Scheppach HP2200S Instruction Manual

 www.scheppach.com /  service@scheppach.com /  +(49)-08223-4002-99 /  +(49)-08223-4002-58  www.scheppach.com /  service@scheppach.com /  +(49)-08223-4002-99 /  +(49)-08223-4002-58
GB
|
21
Explanation of the symbols on the equipment
Symbols are used in this manual to draw your attention to potential hazards. The safety symbols and the accompanying
explanations must be fully understood. The warnings themselves will not rectify a hazard and cannot replace proper ac-
cident prevention measures.
Caution - Read the operating instructions to reduce the risk of inquiry
Use hearing protection. Excessive noise can result in a loss of hearing.
Use safety goggles. Sparks created during work or fragments, chippings and dust ejected
by the device can case sight loss.
Wear work gloves.
Wear safety footwear.
Do not remove or modify protection and safety devices.
Keep away from rotating parts.
No smoking in the working area.
Do not touch hot parts.
Keep children and bystanders off and away.
m Attention! In this operating manual, we have used this sign to mark all sections that concern your safety.
IM_5904612903_HP2200s_191212_new.indd 21IM_5904612903_HP2200s_191212_new.indd 21 12.12.2019 07:40:1912.12.2019 07:40:19

Scheppach HP2200S Specifications

General

Product type	Vibratory plate
Travel speed	25 m/min
Plate material	Steel
Compaction depth	35 cm
Compaction force	25000 N
Fuel tank capacity	3.5 L
Engine displacement	196 cm³
Engine power	6.5 hp
Power source type	Gasoline

Weight and Dimensions

Depth	1025 mm
Width	440 mm
Height	930 mm
Weight	102000 g
Plate depth	550 mm
