PRECAUTIONS WHEN MOVING THE MACHINE
35
7
7-2 SEPARATING THE MAIN CABINET
Handles are provided to ease positioning/re-positioning. Please use these handles. Never move the PTV cabinet by
pushing the screen. Pushing the screen can result in damage.
FIG. 7-2a
● Do not carelessly separate the components of the Main Cabinet. This may lead
to accidents during maintenance and electric shocks or short circuits during
operation.
● After separation of the Gun cabinet from the PTV cabinet, take care which
places you push or pull. Do not turn the components onto their sides. This may
lead to disfigurement or damage and could cause accidents during mainte-
nance. It could even lead to unrepairable damage.
● To work safely and precisely prepare a steady, safety stool or ladder to stand
on. Climbing onto the cabinet or hanging down from it can lead to accidents.
● Perform the separation operation with at least two people. Performing the op-
eration alone could lead to an accident.
If the only way to get the separated components into a desired location is to turn
them onto their side, or if a separation method other than those described in this
manual is required, contact the office listed in this document or the place of pur-
chase. Turning the components onto their side may disfigure or misalign the cabi-
net and could lead to unrepairable damage.
To Next Page
