Sega GHOST SQUAD - EVOLUTION User Manual

74
CONTROL UNIT
11
11-1 HOW TO REPLACE THE MICROSWITCH
To replace the Gun Controller’s internal components, first separate the left shell (Cover L) and right shell (Cover
R). The controller’s internal components are mounted on the right shell, so work with the gun lying on its right
side. To replace the Shot Selector button microswitch, first remove the Shot Selector button from the right shell.
1
Turn off the power.
2
Remove the 15 screws to
seperate the two shells.
FIG. 11-1a
FIG. 11-1b
