Operating Instructions
LMS5xx
Mounting
8013796/ZM63/2017-05-09 © SICK AG · Germany · All rights reserved · Subject to change without notice 59
Chapter 5
5.2.10 Mounting the LMS5xx with protection hood/weather protection hood
To protect the LMS5xx from glare, precipitation and direct sunlight when used outside, a
small protection hood (part no. 2056850) as well as a greater weather protection hood (part
no. 2063050 are available.
The protection hood/weather protection hood can be mounted on the LMS5xx in two
different positions depending on the orientation of the LMS5xx.
You will find detailed dimensions in section 10.3.4 “Dimensional drawings, weather
protection hoods” on page 112.
LMS5xx with protection hood (part no. 2056850)
Fig. 31: Protection hood, upright orientation of the LMS5xx
Fig. 32: Protection hood, upside down orientation of the LMS5xx
