Spare parts
Standard machines_Operating_Instructions_Compact
20 56100000002001 EN, 01/2010
Protective cover, incremental encoder under protective cover
Loosen fastening screws on the external surface of the protective cover.
Under no circumstances should the spacing bolts be disassembled or forcibly
separated from each other or the cover. Forcibly removing or separating the spacing
bolts or fan cover can result in damage to them.
Installation
NOTICE
Avoid damaging the windings protruding out of the stator enclosure when fitting the
end shield.
Spare parts
General
the exact part designation, please specify the machine type and the
0.000 1XP8001 encoder
.02.015 External fan
-1x
In additi
on to
factory serial number in all orders for spare parts.
Directory
These operating instructions can also be obtained at the following Internet site:
<http://www.siemens.com/motors>
General Documentation
1.517.30777.3
5.610.70000
5.610.70000.10.020 Spring-loaded brake
5 610 00002 09 000 Incremental encoder 1XP8012
5 610 00002 09 001 Incremental encoder 1XP8012-2x
