Siemens SED2 Commissioning Manual

30/80
Siemens Building Technologies Commissioning Guide CM1G5192en
HVAC Products 7 Application examples 26.02.2003
7.1.1 Parameter changes
Quick commissioning
Par. no. Value Parameter function Function selection
P0010 1 Start of quick commissioning Quick commissioning
P0304 V Rated motor voltage According to the motor’s rating plate
P0305 A Rated motor current According to the motor’s rating plate
P0307 kW Rated motor power According to the motor’s rating plate
P0310 Hz Rated motor frequency According to the motor’s rating plate
P0311 rpm Rated motor speed According to the motor’s rating plate
P1080 ≥ 10.00 Minimum frequency
P1082 Hz Maximum frequency
P1120 20 s Ramp-up time
P1121 30 s Ramp-down time
P3900 1 End of quick commissioning Calculation of motor and end of quick commissioning
Press and then to round up r0000
Press to access the display
Scaling of DC 0…10 V signals: Example: DC 0…10 V = 10…50 Hz
Par. no. Value Parameter function Function selection
P0003 2 User access level Expert access
P0757(0) 0 Value x1
P0758(0) 20 % Value y1 Minimum frequency at 0 V
P0759(0) 10 Value x2
P0760(0) 100 % Value y2 Maximum frequency at 10 V
Additional parameters
Change of motor’s direction of rotation
Par. no. Value Parameter function Function selection
P0003 3 User access level Expert access
P1820 0/1 Reverse output phase sequence Select 0 or 1
