Siemens SED2 Commissioning Manual

48/80
Siemens Building Technologies Commissioning Guide CM1G5192en
HVAC Products 10 Parameterization 26.02.2003
10 Parameterization
10.1 Block diagram with parameter overview
L1
L2
L3
PE
PE
U
V
W
PE
PE
200 - 240 V 3 AC
380 - 480 V 3 AC
500 - 600 V 3 AC
AOUT1
D / A
20
21
22
Motor
PTC
BOP (Standard)
M
CPU
RS-485
29 30
V: 0 - 10 V
2 - 10 V
I: 0 - 20 mA
4 - 20 mA
13
12
AOUT2
D / A
V: 0 - 10 V
2 - 10 V
I: 0 - 20 mA
4 - 20 mA
27
26
23
24
25
LG-
Ni1000
28
9
5
DIN 1
6
DIN 2
7
DIN 3
8
DIN 4
16
DIN 5
17
DIN 6
14
15
AOP (Optional)
L3L2L1
DC + 10 V
DC + 0 V
3
2
1
LG-
Ni1000
AIN1
2
AIN2
0 V
2
A / D
4
3
V: 0 - 10 V
2 - 10 V
I: 0 - 20 mA
4 - 20 mA
A / D
11
10
V: 0 - 10 V
2 - 10 V
I: 0 - 20 mA
4 - 20 mA
0 V
Analog inputs 1+2
P0756 - P0762
Digital input
P0700
Command source
P0701 - P0706
(P0705 counter)
P0722 - P0725
(NPN - PNP)
Analog inputs 1+2
configured as
digital inputs
P0707 - P0708
PTC
P0601
PID
P2200
P2201 - P2231
P2240 - r2260
P2253 - P2305
P2264 - r2272
Enable PID
Fixed setpoint
PID setpoint
Standard setpoint
PID feedback
Analog output
r0770 - P0781
VSD features
P1270 Enable essential mode
P1210 - P1212 automatic restart
Communication
P2000 - r2091
VSD parameters
P0003
P0010
r0026
r0039 - P0040
P0100
r0206 - r0209
P1000 - P1028
P1080 -P1110
User access level
Commissioning parameter filter
VSD DC link voltage
Energy consumption meter
US / Europe
Performance data
Frequency setpoint
Frequency adjustment
Motor parameters
r0021 - r0035
P0304 - P0313
P0340
P0601 - P0640
P1910
P2000
Motor performance data
Standard data
Calculation of motor parameters
Motor protection
Motor data identification
Reference frequency
DOUT
P0731 - P0732
R0747 - r0748
MMI (BOP)
r0000
P0005
r0019 - r0039
AOP
optional
5192B02en
Relay
output 1
Relay
output 2
Isolated 50 mA@DC 18..32 V
(output)
Isolated 0 V (output)
See AOP operating
instructions
B filter
Opto isolated
