Overview
1.6 Range of HMI software functions
OP 73micro, TP 177micro (WinCC flexible)
Operating Instructions, 09/2007, 6AV6691-1DF01-0AB0
15
Tags, values and lists
Table 1-2 Range of functions for tags, values and lists
Object Specification OP 73micro TP 177micro
Tags Number 500 250
Limit-value monitoring Input Input/Output
Linear Scaling Input/Output Yes Yes
Text lists Number 150 150
Screens
Table 1-3 Range of functions for screens
Object Specification OP 73micro TP 177micro
Number 250 250
Fields per screen 20 20
Tags per screen 20 20
Complex objects per screen (e.g. bars) 5 5
Screen
Template Yes Yes
Infotext
Table 1-4 Range of functions for infotext
Object Specification OP 73micro TP 177micro
Length (no. of characters) 320 320
For alarms Yes Yes
For screens Yes Yes
For screen objects (e.g. IO fields) Yes Yes
Infotext
Help indicator Yes No
