Siemens SIMATIC PP7 User Manual

Index-1
PP7, PP17-I, PP17-II Equipment Manual
Release 06/98
Index
A
Ambient conditions, A-1
Assignment, Control bit, 3-1
Assignment, interface, A-4
Attach labeling strips, 8-1
B
Barometric pressure, A-2
Baud rate, 1-3, 2-1, 2-2, 2-5
Bits, PLC, 3-1
Bouncing time, A-3
Burst interference, A-2
Bus connection, A-4
C
Cable, 4-4
Cable length, maximum, A-4
Checksum, C-2
COM–PROFIBUS, 2-5, 2-6, 2-7, 2-12
Communication, 1-3
Conduction, RF , A-2
Configuration, 1-2
Interface to PLC, 2-3
Keys, 2-9, 2-1 1, 2-12
LEDs, 2-9, 2-1 1, 2-12
PLC, 2-6
Configuration mode, 2-3
Configuring data block, 2-1, 2-5, 2-6, 2-1 1, B-2
Connect
Additional elements, 4-4
Ground, 4-4
Connectable elements, A-2
Connection type, 2-1, 2-2
MPI, 2-1, 2-5, 2-6, 2-1 1, 2-13
PROFIBUS–DP , 2-2, 2-5, 2-6, 2-12
Connection types, 1-2
Contact dischar ge, A-2
Control bit, Assignment, 3-1
Coordination, PLC and Push Button Panel, 2-13
D
Data, technical, A-1
Data area, 2-1
Data block, 2-5, 2-6, 2-1 1
Data transmission, Baud rate, 1-3
Data word, 2-5
Degree of protection, 4-1, A-1
Delay , A-3
Digital inputs, A-2, C-2
Function, 2-10
Numeration, 3-2
Digital outputs, A-3, C-2
Numeration, 3-1
Dischar ge, static, A-2
Display , Messages, B-2
DP slave address, 2-2, 2-5
E
EMV , 4-3
Error LED, Signals, B-1
Error messages, B-2
External dimensions, A-1
F
Front view
PP17–I, 6-1
PP17–II, 7-1
PP7, 5-1
Function keys, 2-9
Fuse, internal, A-1
G
Grounding connection, 4-4
Grounding screw , 4-4
GSD files, 2-7, 2-12
