Parameter List 09.02
5-2 Siemens AG 6SE7087-6AK85-1AA0
Rectifier/Regenerating Unit Operating Instructions
Parameter list; Summary of the abbreviations
Example:
PNU
*
: Conf.
Par.
OP1S - Parameter name
Description
Value range
[phys. unit]
Selection text
Display
Indices
Factory
setting
See
Modify
(access/
status)
P329
1)
8)
Pre-charging time
Pre-charging time of the DC link
RDS parameter
2)
PNU=149Hex; Type=O2;
3)
Scaling: 1Hex
=
∧
1
4)
0 to 9999
[ms]
4
500
9)
3
5)
/ BR
6)
3/ BR
7)
1)
An
*
under the parameter number means that this is a confirmation parameter, i.e. the modified value does not become active until the
P key is pressed.
2)
Abbreviations for indexed parameters
RDS Reserve data set parameter with 4 indices; changeover with control word 2, bits 18 and 19
G/R Parameter with changeover feature for basic and reserve setting in control word 2, bit 30
3)
Specification of parameter type
O2 16-bit value without sign
I2 16-bit value with sign
V2 Bit-coded quantity
L2 Nibble-coded quantity
4)
Scaling for access via the PKW mechanism
If necessary: Specification of scaling group for process data (PZD)
PZD group PZD scaling
0 or no specification As for PKW scaling
1 4000Hex = 100%
5)
Access stage (P051), starting at which a parameter can be modified or displayed
1 Operator input
2 Standard mode
3 Expert mode
4 Factory-set parameters
6)
Specification of the operating states in which the parameter can be displayed
7)
Specification of the operating states in which the parameter can be displayed
6) 7)
Operating states:
U MLFB input
o
000
H Hardware
configuration
o
002,
o
004
A Drive setting
o
005
B Ready (incl.: fault )
o
007,
o
008,
o
009,
o
010,
o
011,
o
012,
o
021
R
(R) Run
o
014,
o
015,
o
018
8)
An
**
under the parameter number means that this parameter does not exist with a 6SE70 rectifier unit (P070 (MLFB) ≥ 101).
9)
A factory setting value in brackets means that the specified value only applies for P077=0. See Section 4.3.9.1 "Generate factory setting"
for more details.
