09.02 Connection
Siemens AG 6SE7087-6AK85-1AA0
3-13
Rectifier/Regenerating Unit Operating instructions
Unit Order No. Rated
input
current
Feed-
back
current
Line voltage
range
±15%
Autotransformer
Duty factor
Autotransformer
Duty factor
Volt. Freq.. 100% 25%
6SE70 (A) (A) (V) (Hz)
41-3FK85-1AA0 1119 1235 500 50/60 4BU6295-0UA11-8A 4BU5695-0UA61-8A
600 60 4BU6295-0UA51-8A 4BU5695-0UA21-8A
41-3FK85-1AD0 1119 1235 500 50/60 4BU6295-0UA11-8A 4BU5695-0UA61-8A
600 60 4BU6295-0UA51-8A 4BU5695-0UA21-8A
41-5FK85-1AA0 1306 1442 500 50/60 4BU6295-0UA21-8A 4BU5895-0UA61-8A
600 60 4BU6295-0UA61-8A 4BU5895-0UA81-8A
41-5FK85-1AD0 1306 1442 500 50/60 4BU6295-0UA21-8A 4BU5895-0UA61-8A
600 60 4BU6295-0UA61-8A 4BU5895-0UA81-8A
41-8FK85-1AA0 1633 1803 500 50/60 4BU6495-0UA01-8A 4BU5995-0UA21-8A
600 60 4BU6395-0UA11-8A 4BU5995-0UA41-8A
41-8FK85-1AD0 1633 1803 500 50/60 4BU6495-0UA01-8A 4BU5995-0UA21-8A
600 60 4BU6395-0UA11-8A 4BU5995-0UA41-8A
31-4HE85-1AA0 123 136 660-690 50/60 4BU4795-0UA31-8A 4BU4395-0UA31-8A
32-2HE85-1AA0 193 213 660-690 50/60 4BU5295-0UA21-8A 4BU4595-0UA51-8A
32-7HE85-1AA0 234 258 660-690 50/60 4BU5395-0UA31-8A 4BU4795-0UA51-8A
34-2HE85-1AA0 366 404 660-690 50/60 4BU5595-0UA11-8A 4BU5295-0UA31-8A
35-3HE85-1AA0 465 514 660-690 50/60 4BU5895-0UA31-8A 4BU5395-0UA51-8A
37-7HH85-1AA0 671 741 660-690 50/60 4BU6095-0UA21-8A 4BU5695-0UA31-8A
41-0HH85-1AA0 898 992 660-690 50/60 4BU6295-0UA31-8A 4BU5895-0UA41-8A
41-3HK85-1AA0 1119 1235 660-690 50/60 4BU6395-0UA01-8A 4BU5995-0UA11-8A
41-3HK85-1AD0 1119 1235 660-690 50/60 4BU6395-0UA01-8A 4BU5995-0UA11-8A
41-5HK85-1AA0 1306 1442 660-690 50/60 4BU6495-0UA11-8A 4BU6095-0UA31-8A
41-5HK85-1AD0 1306 1442 660-690 50/60 4BU6495-0UA11-8A 4BU6095-0UA31-8A
41-8HK85-1AA0 1633 1803 660-690 50/60 4BU6595-0UA01-8A 4BU6295-0UA41-8A
41-8HK85-1AD0 1633 1803 660-690 50/60 4BU6595-0UA01-8A 4BU6295-0UA41-8A
Table 3.7 Recommended autotransformers
