Siemens SINUMERIK 808D Programming And Operating Manual

Cycles
2.4 Drilling cycles
Turning Part 2: Programming (Siemens instructions)
118 Programming and Operating Manual, 05/2012, 6FC5398-5DP10-0BA0
2.4.5 Deep-hole drilling - CYCLE83
Programming
CYCLE83(RTP, RFP, SDIS, DP, DPR, FDEP, FDPR, DAM, DTB, DTS, FRF, VARI, AXN,
MDEP, VRT, DTD, DIS1)
Parameters
Parameter Data type Description
RTP REAL Retraction plane (absolute)
RFP REAL Reference plane (absolute)
SDIS REAL Safety clearance (enter without sign)
DP REAL Final drilling depth (absolute)
DPR REAL Final drilling depth relative to the reference plane (enter without
sign)
FDEP REAL First drilling depth (absolute)
FDPR REAL First drilling depth relative to the reference plane (enter without
sign)
Amount of degression (enter without sign) DAM REAL
Values: >0: degression as value
<0: degression factor
=0: no degression
Dwell time at drilling depth (chip breakage) DTB REAL
Values: >0: in seconds
<0: in revolutions
Dwell time at starting point and for chip removal DTS REAL
Values: >0: in seconds
<0: in revolutions
FRF REAL Feedrate factor for the first drilling depth (enter without sign)
Range of values: 0.001 ... 1
VARI INT Machining type: Chip breakage=0, Chip removal=1
Tool axis AXN INT
Values: 1: 1st geometrical axis
2: 2nd geometrical axis
3: 3rd geometrical axis
MDEP REAL Minimum drilling depth (only in connection with degression
factor)
Variable retraction value for chip breakage (VARI=0) VRT REAL
Values: >0: if traction value
=0: retraction value 1mm set
