Programming principles
1.1 Fundamentals of programming
Turning Part 2: Programming (Siemens instructions)
12 Programming and Operating Manual, 05/2012, 6FC5398-5DP10-0BA0
1.1.6 List of instructions
The functions marked with an asterisk (*) are active at the start of the program in the CNC
turning version, unless otherwise programmed or the machine manufacturer has preserved
the default setting for the "turning" technology.
Address Significance Value assignments Information Programming
D Tool offset number 0 ... 9, only integer, no
sign
Contains compensation data for
a particular tool T... ; D0-
>compensation values= 0,
max. 9 D numbers for one tool
D...
F Feedrate 0.001 ... 99 999.999 Path velocity of a
tool/workpiece;
unit: mm/min or mm/revolution
depending on G94 or G95
F...
F Dwell time (block
with G4)
0.001 ... 99 999.999 Dwell time in seconds G4 F...; separate block
F Thread lead
change (block
containing G34,
G35)
0.001 ... 99 999.999 in mm/rev2 See G34, G35
G G function
(preparatory
function)
Only integer, specified
values
The G functions are divided into
G groups. Only one G function
of a group can be programmed
in a block.
A G function can be either
modal (until it is canceled by
another function of the same
group) or only effective for the
block in which it is programmed
(non-modal).
G...
or symbolic name, e.g.:
CIP
G group:
G0 Linear interpolation at rapid traverse rate 1: Motion commands G0 X... Z...
G1 * Linear interpolation at feedrate (type of interpolation) G1 X...Z... F...
G2 Circular interpolation clockwise G2 X... Z... I... K... F...
;Center and end point
G2 X... Z... CR=... F...
;Radius and end point
G2 AR=... I... K... F...
;opening angle and
center point
G2 AR=... X... Z... F...
;opening angle and end
point
G3 Circular interpolation counter-clockwise G3 ... ; otherwise as for
G2
CIP Circular interpolation through intermediate
point
CIP X... Z... I1=... K1=...
F... ;I1, K1 is intermediate
point
