TC35i: Migration from TC35 to TC35i
PRELIMINARY
TC35_TC35i_MIG_01_V01.01 29.1.2003 Page 14 of 34
^SCTM_B: -2 Alert: T
amb
of board <-25°C. TC35i switches off
immediately.
Alert: T
amb
of board <-29°C. TC35i switches off
immediately.
The table below shows which conditions will wake up TC35 and TC35i from sleep mode
As it can be seen from the following table TC35i supports four sleep modes (5,6,7,8)
more then TC35.
Table 4-6: Wake up from SLEEP mode scenarios
AT+CFUN=5 or 6 ⇒
AT+CFUN=1
AT+CFUN=7 or 8 ⇒
AT+CFUN=1Event
AT+CFUN=0 ⇒
AT+CFUN=1
TC35i only - (TC35 does not support sleep modes: 5-8)*
TC35 TC35i TC35i
Ignition line No No No
/RTS0 or /RTS1 (falling edge) Yes No No
Unsolicited Result Code (URC) Yes Yes No
Incoming voice or data call Yes Yes No
Any AT command (incl. outgoing voice or
data call, outgoing SMS)
Not Possible
(UART disabled)
No No
Incoming SMS depending on mode
selected by AT+CNMI:
AT+CNMI=0,0
(= default, no indication of received SMS)
AT+CNMI=1,1
(= displays URC upon receipt of SMS)
No
Yes
No
Yes
No
No
RTC alarm Yes Yes No
AT+CFUN=1 Not Possible
(UART disabled)
Yes Yes
* TC35i supports SLEEP modes 0, 5, 6, 7 and 8. Different events or commands cause a wake-up from a SLEEP mode. The
detailed descriptions of these modes can be found in respective HID documents.
4.4.4 Battery pack
For some applications the use of a battery pack may be required. TC35 and TC35i can be
powered from a Li-Ion battery:
Table 4-7: Battery specifications - general
General
TC35 TC35i
Supported Charging Technique Trickle charging and processor controlled fast charging
Operating modes SLEEP, IDLE or TALK/DATA mode
Output voltage (for charger) 5.5V...8V (under load)
Charging current Limited to 500mA
Maximum voltage spikes 25V and must not exceed 1ms 15V and must not exceed 1ms
Table 4-8: Battery specifications - charging
Module Battery specification Maximum charging voltage Capacity
TC35 3.6 V 4.2 V 600-800 mAh
TC35i 3.6 V 4.2 V max 850 mAh
