18 - 19
18 Mower Deck Service
54" Mower Housing, Cover & Gauge Wheel Group
REF. QTY. DESCRIPTION
1 2 ARM, Adjusting
2 6 NUT, Hex, Jam, 5/8-18
3 4 WASHER, 5/8
4 2 BOLT, Wheel
5 2 TRUNNION
6 2 CHAIN, 6 Link
7 2 NUT, Hex, Flange Lock, 3/8-16
8 1 COVER, Arbor, RH
9 1 COVER, Arbor, LH
10 4 CLIP, Spring
11 1 HOUSING, 54" Mower Deck
12 2 CLIP, Hairpin
13 4 KLIPRING, 5/8
14 4 WASHER, Plain, 5/8
15 2 SPRING, Compression
16 2 ASSEMBLY, Spindle and Stop
17 2 WHEEL, Gauge
18 4 CAPSCREW, Taptite, 1/4-20 x 3/8
19 1 BAFFLE, Front, Anti-blowout
20 2 BOLT, Carriage, 5/16-18 x 3/4, Grade 5
21 2 NUT, Hex, Nylon Lock, 5/16-18
22 2 BOLT, Carriage, 1/4-20 x 7/8, Grade 5
23 2 NUT, Push
24 1 CLAMP, Wire
25 1 WASHER, Plain, 5/16
26 1 SPRING
27 1 DEFLECTOR, Plastic
28 2 WASHER, Plain, 1/4
29 2 LOCKWASHER, 1/4
30 2 NUT, 1/4-20
31 1 ROD, Deflector, Front
54" Mower Housing, Cover & Gauge Wheel Group
