The Bobbin Thread
Winding the Bobbin
Preparation Steps
1. Raise the presser foot and turn hand wheel
toward you until needle is in highest
position.
2. Loosen hand wheel knob A by turning it
toward you with the right hand white
holding hand wheel with the left hand.
3. Place thread spool on spool pin with thread
retaining slit B to the right. {Break paper at
the end of spool if necessary)
Winding Stops
Lead thread around bobbin winder tension
disc C as illustrated, and through small hole
in bobbin from inside out.
Place bobbin on spindle and move bobbin
winderD to right.
Hold thread end and start the machine. Cut
off thread end after a few coils have been
wound.
When required amount of thread has been
wound (winding will stop when bobbin is
full) stop machine and cut connecting
thread.
Move bobbin winder to the left and remove
bobbin.
Hold hand wheel and tighten hand wheel
knob.
J V
19
