Singer 5560 User Manual

15
Drawing Up the Bobbin Thread
⚠ For safety, turn off the power before threading the machine.
1. Hold the upper thread tail with the left hand (A). Turn the handwheel toward you (B), rst lowering
(C) and then raising the needle (D).
2. As you turn the handwheel, gently pull the upper
thread, which will bring a loop of the bobbin
thread up through the hole of the needle plate
(E). Pull the loop to bring the bobbin thread end
up through the opening in the needle plate.
If a loop doesn’t pull up, turn the handwheel
toward you one more time. If it still doesn’t come
up, check that the bobbin thread is not trapped
in the bobbin case area.
3. Bring both threads under the presser foot and
toward the back of the machine.
A B C D
E
GETTING READY TO SEW

Singer 5560 Specifications

General

Buttonhole Styles	6
Needle Threader	Automatic
Sewing Speed	750 stitches per minute
Display	LCD
Weight	13.6 lbs
Bobbin Type	Top Drop-In
Adjustable Stitch Length	Yes
Adjustable Stitch Width	Yes
Stitch Length	Up to 4mm
Voltage	120V
Warranty	25-year limited
