Singer 5560 User Manual

2
18
LCD Display and Function Buttons
START SEWING
For examples of stitch patterns and further instruction, see the Stitch Reference Guide at
www.singerco.com.
2
1
5
8
3 4
6
7
1. REVERSE/AUTO-LOCK BUTTON sews reverse stitches when pressed for straight and zigzag
stitches. Sews 3 locking stitches when pressed for all other stitches.
2. STITCH NUMBER shows the number of currently selected stitch. (See Page 19)
3. STITCH WIDTH/NEEDLE POSITION shows stitch width of selected stitch/needle position if
straight stitch is selected. (See Page 19)
4. STITCH LENGTH shows stitch length of selected stitch.
5. STITCH SELECTION BUTTONS select desired stitch. (See Page 19)
6. STITCH WIDTH/NEEDLE POSITION ADJUSTMENT BUTTONS let you adjust the stitch width of
selected stitch/needle position if straight stitch is selected. The change is shown instantly on the
LCD display. (See Page 19)
7. STITCH LENGTH ADJUSTMENT BUTTONS let you adjust stitch length of selected stitch. The
change is shown instantly on the LCD display.
8. STITCH NUMBER OVERVIEW shows the numbers of all available stitches for easy selection.

Singer 5560 Specifications

General

Buttonhole Styles	6
Needle Threader	Automatic
Sewing Speed	750 stitches per minute
Display	LCD
Weight	13.6 lbs
Bobbin Type	Top Drop-In
Adjustable Stitch Length	Yes
Adjustable Stitch Width	Yes
Stitch Length	Up to 4mm
Voltage	120V
Warranty	25-year limited
