RadarW
Mode CAMERA
Subject Siemens star
(1.0 m from the front of the lens)
(Luminance: 200 to 400 lux)
Measurement Point Check operation on monitor TV
Measuring Instrument
Specified value Focused at the TELE end and
WIDE end
Checking method:
Order Page Address Data Procedure
1
Place the Siemens star 1.0 m
from the front of the lens.
2
To open the IRIS , decrease
the luminous intensity to the
Siemens star up to a point
before noise appear on the
image.
3
Perform “Data setting during
camera system adjustment”.
(Refer to page 6-14)
4 B 3D Note down the data.
5B 3D50
Press PAUSE button.
(Note 1)
6 6 90 00
7 6 91 04
86 92D0
96 935A
10 6 01 79 Press PAUSE button.
11 6 07
Check the data changes to
“01”.
12 6 2C 01
13 6 01 00 Press PAUSE button.
14
While observe the TV
monitor, change the zoom to
the WIDE end and check that
the lens is focused.
Note 1: How to find the data
Decrease the data of page: B, address: 3D until four sides
of a black frame can be seen on the monitor, then find
the value. The largest value under this condition will be
the setting value. If the value is less than 50, change
monitors.
Processing after Completing Adjustment:
Order Page Address Data Procedure
16 2C00
2 6 91 00
3 6 92 00
4 6 93 00
5B 3D
Set data noted down at step
4, and press PAUSE button.
6
Release the data setting
performed at step 3.
(Refer to page 6-14)
