DSC-F717
6-32
24. CCD Linearity Check (Monitoring)
Check that CCD output at monitoring keeps being straight even
input is changed.
Mode CAMERA
Subject Clear chart
(Standard picture frame with the
zoom lens at WIDE end)
Measurement Point Displayed data of Page: 1 (Note 1)
Measuring Instrument Adjusting remote commander
Specified Value 1 97 to 103 (decimal notation)
Specified Value 2 97 to 105 (decimal notation)
Note 1: The right four digits of the page: 1 displayed data of the
adjusting remote commander.
1:XX:XX
Displayed data
Adjusting method:
Order Page Address Data Procedure
1
Perform “Data setting during
camera system adjustment”.
(Refer to page 6-14)
2
Perform “Picture Frame
setting”. (Refer to page 6-15)
3 7 09 04 Press PAUSE button.
46 C826
56 13A8
6 6 14 90
7 Wait for 2 seconds.
8 0 03 40
9 1 Read displayed data. (Note 1)
10
Get average value of
displayed data of ten times,
and named average value as
D
R/GRef
.
11
Convert D
R/GRef
to decimal
notation, and obtain D
R/GRef
’.
12 0 03 41
13 1 Read displayed data. (Note 1)
14
Get average value of
displayed data of ten times,
and named average value as
D
B/GRef
.
15
Convert D
B/GRef
to decimal
notation, and obtain D
B/GRef
’.
16 B 72 Note down the data.
17 B 72 50 Press PAUSE button.
18 Wait for 2 seconds.
19 0 03 40
20 1 Read displayed data. (Note 1)
21
Get average value of
displayed data of ten times,
and named average value as
D
R/GHi
.
22
Convert D
R/GHi
to decimal
notation, and obtain D
R/GHi
’.
23 0 03 41
Order Page Address Data Procedure
24 1 Read displayed data. (Note 1)
25
Get average value of
displayed data of ten times,
and named average value as
D
B/GHi
.
26
Convert D
B/GHi
to decimal
notation, and obtain D
B/GHi
’.
27 B 72
Set data noted down at step
16, and press PAUSE button.
28 6 14 8B
29 Wait for 2 seconds.
30 0 03 40
31 1 Read displayed data. (Note 1)
32
Get average value of
displayed data of ten times,
and named average value as
D
R/GLow
.
33
Convert D
R/GLow
to decimal
notation, and obtain D
R/GLow
’.
34 0 03 41
35 1 Read displayed data. (Note 1)
36
Get average value of
displayed data of ten times,
and named average value as
D
B/GLow
.
37
Convert D
B/GLow
to decimal
notation, and obtain D
B/GLow
’.
38
Calculate D
1
by using the
following equation. (decimal
calculation)
D
1
= (D
R/GHi
’ ÷ D
R/GRef
’) × 100
39
Check that calculated D
1
satisfies the specified value
1.
40
Calculate D
2
by using the
following equation. (decimal
calculation)
D
2
= (D
B/GHi
’ ÷ D
B/GRef
’) × 100
41
Check that calculated D
2
satisfies the specified value
2.
42
Calculate D
3
by using the
following equation. (decimal
calculation)
D
3
= (D
R/GLow
’ ÷ D
R/GRef
’) × 100
43
Check that calculated D
3
satisfies the specified value
1.
44
Calculate D
4
by using the
following equation. (decimal
calculation)
D
4
= (D
B/GLow
’ ÷ D
B/GRef
’) × 100
45
Check that calculated D
4
satisfies the specified value
1.
To Next Page
