177
Quick Reference
— Quick Reference —
Identifying the parts and controls
1 VF connector (p. 187)
2 MIC IN +48V connector (p. 7)
3 Zoom ring (p. 25)
4 Focus ring (p. 45)
5 START/STOP button (p. 15)
6 SHUTTER switch (p. 40)
Camcorder
INDEX MARK
AUDIO LEVEL
WHT BALSHUTTER
OFF ON
1
2
START/STOP
1
2
3
4
5
6
7
8
9
q;
qa
qs
7 Shoulder strap fitting
8 Accessory shoe
9 IRIS ring (p. 37)
0 INDEX MARK button (p. 53)
qa WHT BAL switch (p. 47)
qs AUDIO LEVEL knob (p. 54)
This mark indicates that this product is a genuine accessory for Sony
video products.
When purchasing Sony video products, Sony recommends that you
purchase accessories with this “GENUINE VIDEO ACCESSORIES”
mark.
These are trademarks.
To Next Page
