Sony DVP-CX777ES Service Manual

139
DVP-CX777ES
SECTION 9
ELECTRICAL PARTS LIST
AV
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-4733-699-A AV BOARD, COMPLETE
******************
* 3-309-144-21 HEAT SINK
7-685-871-01 SCREW +BVTT 3X6 (S)
< CAPACITOR >
C102 1-126-204-11 ELECT CHIP 47uF 20% 16V
C103 1-126-204-11 ELECT CHIP 47uF 20% 16V
C104 1-126-204-11 ELECT CHIP 47uF 20% 16V
C105 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C106 1-126-204-11 ELECT CHIP 47uF 20% 16V
C107 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C108 1-126-204-11 ELECT CHIP 47uF 20% 16V
C109 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C201 1-127-694-11 ELECT 47uF 20% 25V
C204 1-126-767-11 ELECT 1000uF 20% 16V
C205 1-126-193-11 ELECT CHIP 1uF 20% 50V
C206 1-126-193-11 ELECT CHIP 1uF 20% 50V
C209 1-126-193-11 ELECT CHIP 1uF 20% 50V
C210 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C211 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C212 1-127-694-11 ELECT 47uF 20% 25V
C213 1-130-478-00 MYLAR 0.0039uF 5% 50V
C214 1-130-478-00 MYLAR 0.0039uF 5% 50V
C215 1-130-478-00 MYLAR 0.0039uF 5% 50V
C216 1-130-478-00 MYLAR 0.0039uF 5% 50V
C217 1-130-478-00 MYLAR 0.0039uF 5% 50V
C218 1-130-478-00 MYLAR 0.0039uF 5% 50V
C219 1-130-478-00 MYLAR 0.0039uF 5% 50V
C220 1-136-811-11 FILM 330PF 5% 100V
C221 1-136-811-11 FILM 330PF 5% 100V
C222 1-136-356-11 FILM 470PF 5% 100V
C223 1-136-811-11 FILM 330PF 5% 100V
C224 1-136-811-11 FILM 330PF 5% 100V
C225 1-136-811-11 FILM 330PF 5% 100V
C226 1-136-811-11 FILM 330PF 5% 100V
C227 1-136-811-11 FILM 330PF 5% 100V
C228 1-136-818-11 FILM 0.0047uF 5% 100V
C229 1-136-818-11 FILM 0.0047uF 5% 100V
C230 1-136-818-11 FILM 0.0047uF 5% 100V
C231 1-136-356-11 FILM 470PF 5% 100V
C232 1-136-818-11 FILM 0.0047uF 5% 100V
C233 1-136-811-11 FILM 330PF 5% 100V
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
C234 1-136-818-11 FILM 0.0047uF 5% 100V
C235 1-136-811-11 FILM 330PF 5% 100V
C236 1-136-818-11 FILM 0.0047uF 5% 100V
C237 1-136-811-11 FILM 330PF 5% 100V
C238 1-136-818-11 FILM 0.0047uF 5% 100V
C239 1-136-811-11 FILM 330PF 5% 100V
C240 1-136-811-11 FILM 330PF 5% 100V
C241 1-136-811-11 FILM 330PF 5% 100V
C242 1-136-811-11 FILM 330PF 5% 100V
C243 1-127-694-11 ELECT 47uF 20% 25V
C244 1-127-694-11 ELECT 47uF 20% 25V
C245 1-127-694-11 ELECT 47uF 20% 25V
C246 1-127-694-11 ELECT 47uF 20% 25V
C247 1-127-694-11 ELECT 47uF 20% 25V
C248 1-127-694-11 ELECT 47uF 20% 25V
C249 1-127-694-11 ELECT 47uF 20% 25V
C250 1-127-694-11 ELECT 47uF 20% 25V
C251 1-136-850-11 MYLAR 0.1uF 5% 63V
C252 1-128-200-11 ELECT 47uF 20% 50V
C253 1-136-850-11 MYLAR 0.1uF 5% 63V
C254 1-128-200-11 ELECT 47uF 20% 50V
C255 1-136-850-11 MYLAR 0.1uF 5% 63V
C256 1-128-200-11 ELECT 47uF 20% 50V
C257 1-128-200-11 ELECT 47uF 20% 50V
C258 1-136-850-11 MYLAR 0.1uF 5% 63V
C259 1-128-200-11 ELECT 47uF 20% 50V
C260 1-136-850-11 MYLAR 0.1uF 5% 63V
C261 1-128-200-11 ELECT 47uF 20% 50V
C262 1-136-850-11 MYLAR 0.1uF 5% 63V
C263 1-128-200-11 ELECT 47uF 20% 50V
C264 1-136-850-11 MYLAR 0.1uF 5% 63V
C265 1-136-850-11 MYLAR 0.1uF 5% 63V
C266 1-128-200-11 ELECT 47uF 20% 50V
C267 1-137-605-11 MYLAR 0.00022uF 5% 50V
C268 1-137-605-11 MYLAR 0.00022uF 5% 50V
C269 1-137-605-11 MYLAR 0.00022uF 5% 50V
C270 1-137-605-11 MYLAR 0.00022uF 5% 50V
C271 1-137-605-11 MYLAR 0.00022uF 5% 50V
C272 1-137-605-11 MYLAR 0.00022uF 5% 50V
C273 1-137-605-11 MYLAR 0.00022uF 5% 50V
C274 1-137-605-11 MYLAR 0.00022uF 5% 50V
C279 1-126-947-11 ELECT 47uF 20% 16V
C280 1-126-947-11 ELECT 47uF 20% 16V
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
The components identified by mark
0 or dotted line with mark 0 are
critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
