8-2
Ref. No. Part No. Description RemarkRef. No. Part No. Description Remark
* 51 A-6065-569-A FL-114 BOARD, COMPLETE (US, CND)
* 51 A-6065-586-A FL-114 BOARD, COMPLETE (EXCEPT US, CND)
* 52 A-6065-570-A FR-172 BOARD, COMPLETE
* 53 A-6065-573-A BZ-1 BOARD, COMPLETE
* 54 A-6065-583-A AC-114 BOARD, COMPLETE
(EXCEPT US, CND)
* 54 A-6065-595-A AC-113 BOARD, COMPLETE (US, CND)
* 55 A-6065-577-A PS-436 BOARD, COMPLETE (US, CND)
* 55 A-6065-584-A PS-438 BOARD, COMPLETE
(EXCEPT US, CND)
* 56 A-6065-578-A PS-437 BOARD, COMPLETE (US, CND)
* 56 A-6065-585-A PS-439 BOARD, COMPLETE (AEP, UK)
* 56 A-6065-589-A PS-439 BOARD, COMPLETE (HK, CN, AUS)
57 X-3951-186-1 FRAME ASSY, REAR (US, CND)
57 X-3951-187-1 FRAME ASSY, REAR (AEP, UK)
57 X-3951-188-1 FRAME ASSY, REAR (HK, CN, AUS)
58 1-794-774-11 INLET ASSY, AC (US, CND)
58 1-794-774-21 INLET ASSY, AC (EXCEPT US, CND)
59 1-500-386-11 FILTER, CLAMP (FERRITE CORE)
60 3-053-984-11 SCREW (+BV/CU)
61 1-757-069-11 CABLE, FLEXIBLE FLAT (FVE-1) (AEP, UK)
* 62 A-6065-582-A ER-11 BOARD, COMPLETE (AEP, UK)
* 63 A-6065-640-A CO-26 BOARD, COMPLETE
* 64 A-6065-580-A AU-226 BOARD, COMPLETE (AEP, UK)
* 64 A-6065-588-A AU-226 BOARD, COMPLETE (HK, CN, AUS)
* 64 A-6065-593-A AU-226 BOARD, COMPLETE (US, CND)
65 1-757-064-11 CABLE, FLEXIBLE FLAT (FMA-19)
66 1-757-067-11 CABLE, FLEXIBLE FLAT (FMV-21)
* 67 A-6065-581-A VP-52 BOARD, COMPLETE (AEP, UK)
* 67 A-6065-594-A VP-52 BOARD, COMPLETE (EXCEPT AEP, UK)
* 68 A-6065-579-A MB-91 BOARD, COMPLETE (AEP, UK)
* 68 A-6065-587-A MB-91 BOARD, COMPLETE (HK)
* 68 A-6065-590-A MB-91 BOARD, COMPLETE (CN)
* 68 A-6065-591-A MB-91 BOARD, COMPLETE (AUS)
* 68 A-6065-592-A MB-91 BOARD, COMPLETE (US, CND)
69 1-757-066-11 CABLE, FLEXIBLE FLAT (FMF-41)
71 3-312-987-01 CUSHION
* 72 3-669-610-00 SPACER
73 3-063-192-01 +PSTT S4
0 T901 1-435-680-11 TRANSFORMER, POWER (AUDIO) (US, CND)
0 T901 1-435-681-11 TRANSFORMER, POWER (AUDIO)
(EXCEPT US, CND)
0 T902 1-435-683-11 TRANSFORMER, POWER (VIDEO/SYSCON)
(US, CND)
0 T902 1-435-684-11 TRANSFORMER, POWER (VIDEO/SYSCON)
(EXCEPT US, CND)
51
52
53
60
71
60
54
55
56
63
#1
#1
#1
#1
#1
#1
A
B
B
C
C
A
#1
#1
#1
#1
#1
#1
#1
#1
#1
#1
#1
#1
not
supplied
not
supplied
not
supplied
not
supplied
not
supplied
#1
#1
#1
#1
#4
#4
T901
T902
not
supplied
not
supplied
not
supplied
not
supplied
not
supplied
not
supplied
not
supplied
not
supplied
US, CND
US, CND
AEP, UK
not
supplied
64
72
60
60
62
61
60
58
73
59
57
60
60
66
67
65
68
69
60
60
The components identified by
mark 0 or dotted line with
mark 0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour la
sécurité.
Ne les remplacer que par une pièce
portant le neméro spécifié.
8-1-2. CHASSIS ASSEMBLY
