Sony DVP S9000ES - SECTION 2 DISASSEMBLY; Disassembly Procedure

– 5 –
SERVICE NOTE
1. DISASSEMBLY
• This set can be disassembled in the order shown below.
Set
Top Case
(Page 2-1)
Front Panel
(Page 2-1)
Mechanism Deck
(Page 2-2)
MB-91 Board
(Page 2-1)
AU-226 Board
(Page 2-2)
PS-436/437/438/439
Board
(Page 2-2)
FL-114 Board
(Page 2-1)
Optical Pick-up
(Page 2-3)
TK-58 Board
(Page 2-2)
Loading Assembly
(Page 2-3)
Base Assembly
(Page 2-3)
