Sony DVP S9000ES Service Manual

2-2
2-5. PS-436/437/438/439 BOARD
REMOVAL
2-7. MECHANISM DECK REMOVAL
2-6. AU-226 BOARD REMOVAL
2-8. TK-58 BOARD REMOVAL
6 Four screws
(BV3 × 8)
3 Two screws
(BV3 × 8)
4 Two screws
(BV3 × 8)
8 Five screws
(BV3 × 8)
5 Power block
2 Two connectors
(CN307, 309)
7 PS-437 board (US, Canadian)
PS-439 board
(EXCEPT US, Canadian)
9 PS-436 board (US, Canadian)
PS-438 board (EXPECT US, Canadian)
1 Five connectors
(CN201, 203,
204, 206, 207)
7 Two bosses
6 Two screws
(BV3 × 8)
5 Two screws
(BV3 × 8)
4 Three screws
(BV/CU)
8 Two bosses
9 Bracket
(AU)
0 Four screws
(BV3 × 8)
1 Connector
(CN352)
3 Connector
(CN101)
qa AU-226
board
2 Flat cable
(CN351)
1 Connector
(CN102)
4 Mechanism deck
3 Three screws
(BVTP3 × 12)
2 Two flat cables
(CN403, 404)
2 Flexible board
(CN002)
1 Flexible board
(CN001)
4 TK-58 board
3 Two screws
