FST-GTK11iP/GTK33iP/RDH-GTK11iP/GTK33iP
24
2-15. SHIELD (POWER) BLOCK
4 shield (power) block
1 connector
(CN813)
Note 1:
Please spread a sheet under a unit
not to injure front grille.
2 three screws
(BV/ring)
2 two screws
(BV/ring)
2 screw
(BV/ring)
3 two screws
(BVTP3 u 10)
– Top rear view –
Note 2:
When you install the connector, please install themcorrectly.
There is a possibility that this machine damages when not
correctly installing it.
Insert is shallow
Insert is straight
to the interior.
connector
Insert is incline
connector
connector
connector
connector connector
NGOK NG
To Next Page
