74
FST-GTK11iP/GTK33iP/RDH-GTK11iP/GTK33iP
SECTION 7
ELECTRICAL PARTS LIST
GTK11-SMPS BOARD (GTK11iP)
****************
7-685-647-71 SCREW +BVTP 3X10 TYPE2 IT-3
< CAPACITOR >
0 C902 1-112-869-51 CERAMIC 470PF 10% 250V
0 C903 1-112-869-51 CERAMIC 470PF 10% 250V
0 C905 1-114-594-21 FILM 0.22uF 10% 250V
0 C907 1-114-594-21 FILM 0.22uF 10% 250V
0 C909 1-112-869-51 CERAMIC 470PF 10% 250V
0 C914 1-114-347-22 ELECT (BLOCK) 330uF 20% 450V
0 C930 1-114-868-11 CERAMIC CHIP 0.1uF 10% 50V
0 C931 1-162-927-91 CERAMIC CHIP 100PF 5% 50V
0 C932 1-162-968-91 CERAMIC CHIP 0.0047uF 10% 50V
0 C934 1-112-300-91 CERAMIC CHIP 4.7uF 10% 10V
0 C935 1-116-819-51 CERAMIC 560PF 5% 1KV
0 C937 1-107-909-91 ELECT 47uF 20% 50V
0 C939 1-116-393-11 FILM 0.0033uF 5% 400V
0 C941 1-114-160-91 CERAMIC CHIP 1uF 10% 100V
C967 1-114-994-11 ELECT 2200uF 20% 35V
C969 1-112-244-11 ELECT 2200uF 20% 25V
C971 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C976 1-126-965-11 ELECT 22uF 20% 50V
C977 1-100-597-91 CERAMIC CHIP 0.1uF 10% 25V
C980 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
0 CN901 1-564-321-11 PIN, CONNECTOR (3.96 mm PITCH) 2P
< DIODE >
0 D902 8-719-077-77 DIODE D3SB60F3
0 D931 6-503-044-01 DIODE DZ2J360M0L
0 D932 6-503-036-01 DIODE DZ2J220M0L
0 D933 6-503-032-01 DIODE DZ2J180M0L
0 D934 6-503-030-01 DIODE DZ2J160M0L
0 D938 6-503-731-01 DIODE SARS10
0 D940 8-719-063-74 DIODE D1NL20U-TR2
0 D941 8-719-083-71 DIODE UDZSUSTE-1730B
D965 6-501-849-01 DIODE FMX-22SL
D967 6-503-458-01 DIODE RK49LF-T1
0 D972 8-719-074-75 DIODE PTZ-TE25-30B
< FUSE >
0 F901 1-523-067-51 FUSE (5 A/250 V)
0 F931 1-523-085-11 FUSE (2.5 A/250 V)
< IC >
0 IC930 6-716-855-01 IC STR-Y6766
IC932 6-711-947-01 IC MM1431CURE
< COIL >
0 L903 1-456-082-11 COIL, LINE FILTER
0 L904 1-456-082-11 COIL, LINE FILTER
L966 1-457-878-65 CHOKE COIL 2.2uH
L967 1-457-578-11 CHOKE COIL 10uH
< PHOTO COUPLER >
0 PH930 6-600-276-01 PHOTO COUPLER PS2561AL1-1-V-W
< TRANSISTOR >
0 Q930 6-552-502-01 TRANSISTOR DSC7003R0L
Q970 8-729-620-13 TRANSISTOR 2SC4154TP-1EF
< RESISTOR >
0 R901 1-240-938-51 METAL 1.5M 5% 0.5W F
0 R914 1-248-270-15 FUSIBLE 0.33 10% 1W F
0 R933 1-257-117-11 METAL 0.33 5% 2W F
0 R934 1-257-117-11 METAL 0.33 5% 2W F
0 R935 1-218-855-91 METAL CHIP 2.2K 0.5% 1/10W
0 R936 1-218-887-91 METAL CHIP 47K 0.5% 1/10W
0 R937 1-216-829-91 METAL CHIP 4.7K 5% 1/10W
0 R938 1-218-881-91 METAL CHIP 27K 0.5% 1/10W
0 R939 1-216-845-91 METAL CHIP 100K 5% 1/10W
0 R944 1-215-929-51 METAL OXIDE 100K 5% 3W F
0 R945 1-216-809-91 METAL CHIP 100 5% 1/10W
0 R947 1-216-793-91 METAL CHIP 4.7 5% 1/10W
R965 1-216-821-11 METAL CHIP 1K 5% 1/10W
R971 1-216-849-11 METAL CHIP 220K 5% 1/10W
R972 1-216-864-11 SHORT CHIP 0
R975 1-216-864-11 SHORT CHIP 0
R976 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R977 1-218-883-11 METAL CHIP 33K 0.5% 1/10W
R978 1-218-863-11 METAL CHIP 4.7K 0.5% 1/10W
R987 1-216-821-11 METAL CHIP 1K 5% 1/10W
R989 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R990 1-216-833-11 METAL CHIP 10K 5% 1/10W
0 R991 1-215-871-51 METAL OXIDE 2.2K 5% 1W F
0 R992 1-215-871-51 METAL OXIDE 2.2K 5% 1W F
0 R995 1-215-871-51 METAL OXIDE 2.2K 5% 1W F
0 R996 1-215-871-51 METAL OXIDE 2.2K 5% 1W F
0 R1009 1-216-793-91 METAL CHIP 4.7 5% 1/10W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
• Abbreviation
AUS : Australian model
E2 : 120V AC area in E model
E51 : Chilean and Peruvian models
EA : Saudi Arabia model
MX : Mexican model
RU : Russian model
SP6 : Singapore and Malaysia models
Note: When the C905, C914, C967, C969, L903, L904, R933 and R934 on the GTK11-SMPS board are replaced,
spread the bond referring to “BOND FIXATION OF ELECTRIC PARTS” on servicing notes (page 6).
GTK11-SMPS
