HCD-VM330AV
12
3-11. BU HOLDER ASSY
3-10. BASE UNIT
(BU-30ABD61A)
1
three screws
(BVTP3
×
8)
2
bracket (top 60)
3
base unit
(BU-30ABD61A
)
4
BU holder assy
1
tension spring (F1)
2
tension spring (F-2)
3
two screws
(PTP2.6
×
8
)
3
two screws
(PTP2.6
×
8)
